MULTICOMP PRO MC0125W120615R10 Thick Film Resistor
The Multicomp Pro MC series thick film chip resistors deliver resistance values from 1 ohm to 10 megaohms, suitable for surface-mount applications. Available in SMD sizes 0402, 0603, 0805, and 1206, these resistors are lightweight, compact, and support wave and reflow soldering, reducing assembly costs. They withstand maximum voltages up to 50V, 150V, and 200V depending on size, with tolerance levels of ±1%, ±2%, and ±5%. Temperature coefficient of resistance ranges from ±400ppm/°C to ±100ppm/°C, with operating temperatures from -55°C to +155°C. Power ratings are 62.5mW, 100mW, and 125mW, making them ideal for precision electronic circuits.
MULTICOMP PRO MC0125W120615R10 Thick Film Resistor Specifications:
- Size: 0402, 0603, 0805, 1206
- Resistance Range: 1Ω to 10MΩ
- Tolerance: ±1%, ±2%, ±5%
- Power Ratings: 62.5mW, 100mW, 125mW
- Maximum Working Voltage: 50V (0402, 0603), 150V (0805), 200V (1206)
- Temperature Coefficient: ±400ppm/°C (1Ω–10Ω), ±200ppm/°C (11Ω–100Ω), ±100ppm/°C (>100Ω)
- Operating Temperature Range: -55°C to +155°C
- Support: Wave and reflow soldering
Buy the Multicomp Pro MC – Reliable Surface-Mount Resistors for Industrial Applications
Upgrade your electronic assemblies with Multicomp Pro thick film surface-mount resistors in sizes 0402, 0603, 0805, and 1206. These resistors are precision-engineered for high reliability and optimal performance, supporting resistance values up to 10 megaohms. With tolerances of ±1%, ±2%, and ±5%, and temperature coefficients as low as ±100ppm/°C, they are suitable for demanding applications across various industries. Easy to solder with wave or reflow processes, they ensure reduced assembly time and costs. Trust Multicomp Pro for consistent quality and excellent durability in your manufacturing needs.
Order your Multicomp Pro MC series thick film resistors today and ensure your projects benefit from dependable, high-quality surface-mount components.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC0125W120615R10?
You can click on the BUY or RFQ button to purchase MC0125W120615R10 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC0125W120615R10?
You can download the MC0125W120615R10 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC0125W120615R10?
MULTICOMP PRO
