MULTICOMP PRO MC25126 Power relay
The MC25126 is a power relay featuring silver alloy contacts and a sealed plastic enclosure. It has a coil power consumption of 540mW and a 1-form-C contact configuration. The relay is rated for 100,000 electrical operations and 10,000,000 mechanical operations. It offers a minimum insulation resistance of 1 gigaohm at 500VDC, with a maximum operate time of 15 milliseconds and a maximum release time of 8 milliseconds. The operating temperature range is from -30°C to 70°C. Suitable for industrial and power management applications, this relay is part of the Multicomp Pro product line rated highly by users.
MULTICOMP PRO MC25126 Power relay Specifications:
- Contact Form: 1 form C
- Contact Material: Ag Alloy
- Contact Rating Resistive: 10A 250V ac/30V dc
- Inductive: 5A 240V AC (Cos φ=0.4)
- Max. Switching Voltage: 250V AC/30V DC
- Max. Switching Current: 210A
- Max. Switching Power: 2,500VA, 300W
- Min. Switching Load: 5V DC, 100mA
- Max. Contact Resistance: Max. 100mΩ (6V DC 1A)
- Number of Operations Electrical: 100,000
- Mechanical: 10,000,000 operations
- Insulation Resistance: Min. 1,000 MΩ at 500V DC
- Dielectric Strength: 1,000V AC, 1 min between open contacts; 4,000V AC, 1 min coil to contacts
- Operate Time: Max. 15ms
- Release Time: Max. 8ms
- Operating Temperature Range: -30°C to +70°C
- Coil Power Consumption: 540mW
- Operating Humidity: 35% to 95% RH at +40°C
- Shock Resistance: 1000m/s²
- Vibration Resistance: 100m/s²
- Dimensions: 20.6mm width, 16.5mm mounting hole spacing, 12.6mm height
- Certifications: UL Listed
Buy the Buy Multicomp Power Relay Part Number MC25126 Online
Purchase the Multicomp Power Relay MC25126 online today for dependable industrial switching solutions. Featuring silver alloy contacts, sealed enclosure, high durability, and a wide temperature range, it ensures reliable operation in power management and automation systems. With high electrical endurance of 100,000 operations, mechanical longevity of 10 million cycles, and fast response times, this relay is designed for demanding environments. Order now to enhance your system’s reliability with a trusted, UL-listed component that meets stringent industrial standards.
Get Multicomp MC25126 today—built for industrial power management with high endurance and reliable switching performance.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MC25126?
You can click on the BUY or RFQ button to purchase MC25126 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MC25126?
You can download the MC25126 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MC25126?
MULTICOMP PRO
