MULTICOMP PRO MCFE03025 Toroidal Transformer
This toroidal transformer is a versatile electronic component designed for efficient power transfer in various electrical applications. It features a 30VA power rating, multiple secondary voltage options including 6V, 9V, 12V, 15V, 18V, and 25V, with high-quality UL1015 rated leads rated for 600V at 105°C. The transformer offers an 86% typical efficiency, a compact size with an outer diameter of 81.3mm and height of 39mm, and a weight of 0.62kg. Its insulation classes include Class H winding wire and Class B insulation system, ensuring safe and reliable operation. RoHS compliance enhances its environmental friendliness.
MULTICOMP PRO MCFE03025 Toroidal Transformer Specifications:
- Power Rating: 30VA
- Primary Voltage: 230V 50/60Hz
- Secondary Voltages: 6V, 9V, 12V, 15V, 18V, 25V
- Secondary Current: varies with voltage (6V: 6.9Ω, 9V: 10.3Ω, 12V: 13.7Ω, 15V: 17.1Ω, 18V: 20.6Ω, 25V: 28.4Ω)
- Input Resistance: 87Ω 215% @ 20°C
- Magnetising Current: approx. 4mA @ 230V 50Hz
- Iron Losses: approx. 0.39 Watts
- Copper Losses: approx. 4.3 Watts
- Efficiency: 86% typical
- Dimensions: Outer Diameter 81.3mm, Height 39mm
- Weight: 0.62kg
- Insulation: Class H winding wire, Class B insulation system, Leadout insulation Class A
- Lead Lengths: approx. 5mm, Tinned ends
- Termination: UL1015 style cable rated 600V/105°C, double insulated primary leads with PVC sleeving
Buy the Buy Multicompro Toroidal Transformer Part Number MCFE03025 Online
Purchase your reliable 30VA toroidal transformer online today. Designed for efficient power conversion, it features multiple secondary voltages, UL-rated leads, and RoHS compliance. Compact and lightweight, this transformer ensures safe insulation with Class H winding wire and Class B insulation system. Its high efficiency of 86% minimizes energy loss, offering a durable solution for electrical applications. Easy to install with insulated leads, this transformer is perfect for both DIY projects and professional installations. Make your purchase now for dependable, high-performance power management.
Order your Multicompro Toroidal 30VA Transformer Part Number MCFE03025 today and ensure reliable power delivery for your electrical projects with high-quality components.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCFE03025?
You can click on the BUY or RFQ button to purchase MCFE03025 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCFE03025?
You can download the MCFE03025 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCFE03025?
MULTICOMP PRO
