MULTICOMP-PRO MCKSK6R3M222G16S Aluminium Capacitor
The multicomp MCKSK series aluminium electrolytic capacitors are high-temperature rated up to 105°C, suitable for general-purpose applications. They feature capacitance tolerance of +20% at 120Hz, with operating temperatures spanning -40°C to +105°C, rated voltages from 6.3V to 450V, and low leakage current. Their impedance ratio varies with temperature and voltage, ensuring stability across diverse conditions. These capacitors support 2000-hour load life at 105°C, with capacitance and leakage current within set limits, making them reliable for industrial and power supply applications.
MULTICOMP-PRO MCKSK6R3M222G16S Aluminium Capacitor Specifications:
- Capacitance Tolerance: +20% at 120Hz, 20°C
- Operating Temperature Range: -40°C to +105°C
- Rated Voltage Range: 6.3V to 450V
- Leakage Current: ≤0.01CV or 3uA after 2 mins at rated voltage
- Dissipation Factor (tan δ): Max 0.24 at 120Hz, 20°C
- Impedance Ratio (Z(-25°C)/Z(20°C)): Max 4 at 6.3V, up to 15 at 50V-100V
- Load Life: 2000 hours at 105°C, capacitance ±25%, leakage current within initial value
- Shelf Life: Capacitance within +20% of initial, leakage current within initial
Buy the Multicomp Series6R3M222G16S – Reliable Aluminium Capacitors for Industrial Applications
Discover the multicomp aluminium electrolytic capacitor series, engineered for high-temperature environments up to 105°C. These capacitors offer broad voltage options from 6.3V to 450V, with high capacitance tolerances suitable for power supplies, industrial equipment, and electronic circuits. They feature low leakage current, excellent stability, and a long 2000-hour load life at operating temperature. Trust in their durability and reliable performance to ensure your projects remain efficient and stable over time. Buy online now for quality and performance.
Order your multicomp Series6R3M222G16S aluminium electrolytic capacitor today and enhance your power supply or industrial projects with dependable quality.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO MCKSK6R3M222G16S?
You can click on the BUY or RFQ button to purchase MCKSK6R3M222G16S from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part MCKSK6R3M222G16S?
You can download the MCKSK6R3M222G16S datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of MCKSK6R3M222G16S?
MULTICOMP-PRO
