MULTICOMP PRO MCTR100JDD1002 Power Resistor
The MCTR100JDD1002 is a high-power resistor capable of handling up to 100 watts at 25°C case temperature, mounted on a heat sink. Featuring a TO-247 style package, this resistor offers reliable performance with non-inductive, molded case construction for protection and easy mounting via a single M3 screw. It is electrically isolated, RoHS compliant, and suitable for applications such as gate resistors in power supplies, snubbers, load resistors in CRT monitors, terminal resistances in RF power amplifiers, voltage regulation, and UPS systems. Its construction includes alumina substrate, resistor layer, lead, and molding materials designed for durability and heat dissipation.
MULTICOMP PRO MCTR100JDD1002 Power Resistor Specifications:
- Power: 100 Watts at 25°C case temperature
- Package: TO-247 style
- Mounting: Single M3 screw to heat sink
- Construction: Molded case, electrically isolated
- Material: Alumina substrate, non-inductive design
- Resistance Range: 0.05Ω to 1000kΩ
- Temperature Coefficient: No specific value specified, -65°C to +175°C operating temperature
- Operating Voltage: 700V Max.
- Dielectric Strength: 1,800V AC
- Insulation Resistance: 10GΩ minimum
- Lead Material: Tinned Copper; Torque: 0.9 Nm
- Thermal Rating: 3.5W in free air at 25°C
- Environmental: Load life 2000 hours at rated power, vibration 20g peak
Buy the Multicomp Series Power Resistor: MCTR100JDD1002
Purchase the Multicomp Series Power Resistor MCTR100JDD1002 online today to ensure reliable high-power performance in your applications. Designed for 100W handling capability at 25°C case temperature, it features a durable molded case, non-inductive construction, and excellent heat dissipation. Perfect for power supplies, snubbers, RF load resistors, voltage regulation, and UPS systems, this resistor offers easy mounting with a single M3 screw, making it ideal for both professional and DIY projects requiring robust and dependable components.
Get Multicomp Series Power Resistor MCTR100JDD1002 today—built for precision, durability, and high-power applications.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MCTR100JDD1002?
You can click on the BUY or RFQ button to purchase MCTR100JDD1002 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MCTR100JDD1002?
You can download the MCTR100JDD1002 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MCTR100JDD1002?
MULTICOMP PRO
