MULTICOMP PRO MCUMHR6V3107M63X5 Miniature Radial Capacitor
This ultra-miniature radial electrolytic capacitor from multicomp pro is designed for high-density electronic devices, offering a short body length of just 5mm. It operates within a temperature range of -40°C to +85°C and features a rated voltage of 6.3V. With a capacitance of 100uF and tolerance of +20%, it ensures reliable performance in compact applications like automotive, consumer electronics, and office machines. The capacitor withstands high temperatures, after 1,000 hours at +85°C, it maintains capacitance and low leakage current, making it ideal for space-constrained electronic designs.
MULTICOMP PRO MCUMHR6V3107M63X5 Miniature Radial Capacitor Specifications:
- Operating temperature range: -40°C to +85°C
- Rated working voltage: 6.3V DC
- Nominal capacitance: 100uF
- Capacitance tolerance: +20% at +20°C, 120Hz
- Leakage current: | = 0.01 CV or 3 (yA) after two minutes
- Dissipation factor: Max tan 6 at 6.3V, 120Hz / +20°C, 0.24
- Dimensions: 5x5mm (diameter x height)
- Shelf life: Maintains performance after storage at +105°C for 500 hours
- High temperature loading: Leakage current < initial value, Capacitance change within +20%, Dissipation factor < 200%, after 1000 hours at +85°C
- RoHS compliant, solvent-proof, suitable for ultrasonic cleaning in Freon TE
Buy the Buy Multicomp Capacitors Part Number MCUMHR6V3107M63X5 Online
Secure your Electronic Components with multicomp:pro's ultra-miniature radial capacitor, rated 6.3V and 100uF. Designed for high-density devices, it offers excellent stability from -40°C to +85°C. This compact capacitor withstands harsh conditions, including high temperatures of +105°C, while maintaining capacitance and low leakage current. Perfect for automotive, consumer electronics, and office equipment, it ensures long-lasting, high-performance operation in limited space. Order now online for fast delivery and reliable performance in your electronic projects.
Buy Multicomp MCUMHR6V3107M63X5 now and experience reliable performance in space-efficient electronic applications.
