MULTICOMP PRO MP001244 Red Through Hole LED
This through-hole red LED features a 3mm (T1) size with high luminous intensity, wide viewing angle of 25 degrees, and RoHS compliance. Designed for various industrial applications, it operates with a forward current of 30mA and has a reverse voltage of 5V. The LED uses AlGaInP chip material, with a lens color code of red and an epoxy resin. Its package includes Ag plating on the lead frame, ensuring durability and performance across a temperature range of -30°C to +80°C operating and -40°C to +100°C storage temperatures, with a junction temperature of 110°C.
MULTICOMP PRO MP001244 Red Through Hole LED Specifications:
- Lens Colour: Red
- Size: 3mm (T1)
- Forward Current: 30mA
- Reverse Voltage: 5V
- Wavelength: 620-630 nm
- Luminous Intensity: 1300-2500 mcd
- Viewing Angle: 25 degrees
- Operating Temperature: -30°C to +80°C
- Storage Temperature: -40°C to +100°C
- Junction Temperature: +110°C
- Lead Frame: Silver Plated Iron Alloy
- Resin Material: Epoxy
- Chip Material: AlGaInP
- Reverse Current: 10 pA at 8V
- Pulsed Forward Current: 100mA with 1/10 duty cycle and 0.1ms pulse width
Buy the Multicomp MP001244 – Reliable Red Through-Hole LED for Industrial Use
Purchase the multicomp MP001244 red through-hole LED online today and ensure your industrial projects benefit from reliable, high-performance indicator lights. With a 3mm size, 25-degree viewing angle, and high luminous intensity of up to 2500mcd, this LED is ideal for various applications requiring bright, consistent illumination. Its durable epoxy resin and silver-plated lead frame enhance longevity and performance across wide temperature ranges, making it a preferred choice for electronics, industrial equipment, and indicator lighting in demanding environments.
Order your multicomp series MP001244 red through-hole LED today and give your projects the dependable quality they deserve with high luminous intensity and excellent durability.
