MULTICOMP PRO MP004317 Ceramic Cartridge Fuse
The Time-Lag Ceramic Cartridge Fuse is an axial leaded fuse with a 6.3mm diameter and 32mm length, designed for reliable overcurrent protection in industrial and electronic applications. Made from ceramic with nickel-plated brass caps and wire leads of varied thickness for ratings above 13A, this fuse provides precise limit ratings with high interrupting capacity up to 10,000A at 125V AC. Suitable for circuit protection in various environments, it ensures durability, compliance with RoHS, UL, and CSA standards, and is ideal for use in power supplies, automation systems, and industrial equipment.
MULTICOMP PRO MP004317 Ceramic Cartridge Fuse Specifications:
- Body Material: Ceramic
- Cap Material: Nickel Plated Brass
- Lead Wire Diameter: 0.8 mm (up to 12A), 1.0 mm (above 13A to 19A), 1.2 mm (above 20A)
- Dimensions: Diameter 6.3mm, Length 32mm, Total Length with Cap 33mm ± 0.75mm
- Operating Temperature Range: -55°C to 125°C
- Interrupting Rating: Up to 10,000A at 125V AC
- Rated Current: 800mA to 30A
- Rated Voltage: 125V AC / 250V AC
- Certificates: UL Listed, CSA Certified, RoHS Compliant
- Part Number: MP004317 to MP004338 (various ratings)
Buy the Multicomp Time-Lag Ceramic Fuse – Reliable Circuit Protection for Industrial Applications
Discover the high reliability and excellent performance of the Multicomp ceramic cartridge fuse, designed for circuit protection in various industrial and electronic equipment. With a size of 6.3mm x 32mm, it offers high interrupting capacity up to 10,000A at 125V AC, ensuring safety and durability. The fuse features ceramic body, nickel-plated brass caps, and varied wire diameters for ratings above 13A, complying with RoHS, UL, and CSA standards. Perfect for power supplies, automation, and industrial machinery, this fuse guarantees dependable operation and compliance in demanding environments.
Buy Multicomp ceramic cartridge fuse now and ensure high-performance circuit protection suitable for industrial, automation, and electronic systems.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP004317?
You can click on the BUY or RFQ button to purchase MP004317 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP004317?
You can download the MP004317 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP004317?
MULTICOMP PRO
