MULTICOMP PRO MP004323 Ceramic Cartridge Fuse
This time-lag ceramic cartridge fuse with axial leads is designed for reliable overload protection in various electronic and electrical applications. With a size of 6.3mm x 32mm, it features a ceramic body and nickel-plated brass caps for durability and conductivity. Suitable for current ratings from 800mA to 30A, it offers high interrupting ratings up to 10,000 amperes at 125V AC. Designed to operate from -55°C to 125°C, it provides fast response times and stable performance in demanding environments, complying with RoHS standards for eco-friendliness.
MULTICOMP PRO MP004323 Ceramic Cartridge Fuse Specifications:
- Size: 6.3mm x 32mm
- Body Material: Ceramic
- Caps Material: Nickel Plated Brass
- Lead Wire Diameter: 0.8 mm for 12A and less, 1.0 mm for 13A-19A, 1.2 mm for above 20A
- Operating Temperature: -55°C to 125°C
- Interrupting Rating: Up to 10,000A at 125V AC
- Current Ratings: 800mA to 30A
- Voltage Ratings: 125V AC, 250V AC
- Certifications: UL Listed, CSA Certified
- Dimensions: Body length 31.75 mm, total length with caps 33 mm
- Rated load: 100% Rating, 135% Rating, 200% Rating
- Time-Delay: 4 hours at rated current, fast trip options 2 sec to 120 sec
- Agency Approvals: UL, CSA, PSE
- Compatibility: Suitable for overload protection in power supplies and industrial circuits
Buy the Multicomp Time-Lag Ceramic Cartridge Fuse – Reliable Overload Protection for Industrial Applications
Shop the Multicomp ceramic cartridge fuse MP004323 now and ensure reliable overload protection for your electrical circuits. With ratings from 800mA to 30A and high interrupting capacity up to 10,000A, this ceramic fuse is ideal for industrial, commercial, and electronic applications. Its durable ceramic body and nickel-plated brass caps provide long-lasting performance. Compatible with various voltages and operating temperatures, it meets UL, CSA, and PSE standards. Purchase online today for fast delivery and peace of mind in your electrical protection solutions.
Buy Multicomp ceramic cartridge fuse MP004323 now and experience reliable overload protection suitable for demanding industrial and electronic applications.
