MULTICOMP PRO MP006213 Snap Action Microswitch
This snap action microswitch features a long hinge lever with a SPDT contact configuration, suitable for automation, household appliances, and automotive applications. It offers a contact rating of 2A at 12V DC, with mechanical durability of over 1 million cycles and electrical durability of at least 100,000 cycles. The device is sealed IP67, operates in temperatures from -40°C to +85°C, and provides reliable switching with various actuator options, including pin plungers and levers. Its compact design makes it ideal for precise and rugged switching needs in demanding environments.
MULTICOMP PRO MP006213 Snap Action Microswitch Specifications:
- Contact Rating: 2A at 12V DC, 1A at 24V DC
- Mechanical Durability: 1,000,000 cycles minimum
- Electrical Durability: 100,000 cycles minimum
- Contact Resistance: 150mΩ max
- Insulation Resistance: 100MΩ min at 500V DC
- Dielectric Strength: 600V AC between terminals; 1500V AC between terminals and ground
- Operating Temperature: -40°C to +85°C
- Sealed IP67
- Contact Form: SPDT
- Actuators: Pin plunger, lever options
- Dimensions: Compact size, approximately 13.3mm x 5.3mm x 7.2mm
- RoHS Compliant
Buy the Buy multicomp Snap Action Microswitch Part Number MP006213 Online
Shop online today for the multicomp Snap Action Microswitch MP006213. With high durability and sealed IP67 protection, this switch is ideal for automotive, household, and industrial applications. Its compact size, multiple actuator options, and proven electrical and mechanical lifespan ensure reliable operation across a wide temperature range. Perfect for sensitive automation systems requiring precise switching. Purchase now to benefit from fast shipping, trusted quality, and expert support, making your projects safer and more efficient with this versatile microswitch designed for demanding environments.
Order your multicomp Snap Action Microswitch MP006213 today and ensure reliable, rugged switching performance suited for demanding automation and automotive projects.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP006213?
You can click on the BUY or RFQ button to purchase MP006213 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP006213?
You can download the MP006213 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP006213?
MULTICOMP PRO
