MULTICOMP PRO MP007040 SMD Crystal
This high-precision, RoHS-compliant SMD crystal measures 5mm x 3.2mm x 1.2mm, designed for compact electronic devices such as GPS, PDAs, and servers. Featuring low profile, excellent heat resistance, and stability with a frequency of 22.1184MHz, it provides stable timing solutions across a temperature range of -20°C to +70°C. Suitable for applications requiring high accuracy, low drive level, and specific load capacitance options of 18pF or 20pF, it ensures reliable performance in demanding environments. Its sealed glass design contains Pb, meeting industry standards.
MULTICOMP PRO MP007040 SMD Crystal Specifications:
- Frequency: 22.1184MHz
- Size: 5mm x 3.2mm x 1.2mm
- Tolerance: ±30ppm at 25°C
- Stability: ±30ppm over temperature
- Operating Temperature Range: -20°C to +70°C
- Storage Temperature Range: -40°C to +85°C
- Shunt Capacitance: 18pF or 20pF
- Drive Level: 1pW to 200uW (typical 100uW)
- Equivalent Series Resistance: Max. 500Ω
- Contains Pb in sealed glass (RoHS exempted)
- Application: GPS, PDA, Smart factory, AV equipment, PC, Server
Buy the Buy Multicomp SMD Crystal Part Number MP007040 Online
Purchase the Multicomp SMD Crystal MP007040 online today for reliable, high-precision timing in your electronic projects. Its compact size, excellent heat resistance, and stable frequency at 22.1184MHz make it perfect for GPS devices, servers, and smart electronics. Designed to operate within -20°C to +70°C, this sealed glass crystal contains lead but complies with RoHS standards. Enjoy fast delivery, secure checkout, and trusted quality for your critical applications. Order now and ensure optimal timing performance in your designs!
Get Multicomp MP007040 today—designed for precision and long-lasting durability in compact electronics.
Frequently Asked Questions
Where can I buy MULTICOMP PRO MP007040?
You can click on the BUY or RFQ button to purchase MP007040 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part MP007040?
You can download the MP007040 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of MP007040?
MULTICOMP PRO
