MULTICOMP PRO PAL6B2M1CESG35 Sub-Miniature Pushbutton Switch
The paddle switch series offers reliable, high-quality sub-miniature pushbutton switches designed for precision control in industrial electrical applications. Constructed with durable materials such as polyamide and diallyl phthalate, these switches feature various mounting options, contact configurations, and high dielectric strength up to 1,500 VAC rms. Rated for resistive loads up to 2A at 125V AC or 100mA at 24V DC, with a switch life expectancy of 200,000 cycles, suitable for panel mounting, automation, and control systems, ensuring long-lasting performance under diverse operating conditions.
MULTICOMP PRO PAL6B2M1CESG35 Sub-Miniature Pushbutton Switch Specifications:
- Max. Current/Voltage Rating: 2A 125V AC, 100mA 24V DC
- Initial Contact Resistance: 50mΩ Max.
- Insulation Resistance: 1GΩ min. @ 500V DC
- Dielectric Strength: 1,500 VAC rms.
- Electrical Life at Full Load: 200,000 cycles
- Operating Temperature: 30°C to 85°C
- Panel Thickness: 1.5mm (0.059") min. ~ 4mm (0.157") max.
- Total Travel: 1.5mm (0.059")
- Operating Force: 2N~5N
- Contact Bounce: 10ms
- Mechanical Life: 1,000,000 cycles
- Torque: 0.5Nm max. to nut
- Soldering: Max 350°C for 5 seconds
- Lead-Free compliant
- Switch Function: SPST, Off-Mom, On-Mom (Momentary), with various hardware options
- Materials: Case - diallyl phthalate (UL94V-0), Cap - Polyamide 6/6, Bushing - Polyamide 6/6
- Bushing Plating: Chromium, Stain-nickel, or Stain-chromium
- Termination Options: Solder lug, PC thru-hole
- Hardware: M12 nut, lock washer, O-ring
- Wire: UL approved multi-wire lead AWG20, 0.6mm section, lengths vary (L1=500mm, L2=90mm, L3=100mm)
Buy the Multicomp Series Sub-Miniature Pushbutton Switch Part Number PAL6B2M1CESG35
Discover the high-quality sub-miniature pushbutton switch designed for durability and precision. Perfect for automation, control panels, and industrial systems, this switch features robust materials, high dielectric strength, and a long electrical life of up to 200,000 cycles. Easy to install with multiple termination options, it withstands harsh environments with an operating temperature range of 30°C to 85°C. Ensure reliable performance in your projects by ordering this versatile switch online today for seamless integration into your control solutions.
Buy Multicomp PAS6B2M1CESG35 now and experience unmatched reliability and performance for your industrial control needs.
