MULTICOMP PRO S1A Power Rectifier
The surface mount glass passivated rectifier is designed for high-reliability applications, offering low reverse leakage current and high current capability. Its mold case with UL 94V-0 flammability classification ensures safety and durability. Suitable for resistive or inductive loads, it features a wide reverse voltage range from 50V to 1000V and a forward current of 1A. The device's low junction capacitance of 10 pF and thermal resistance of 30°C/W make it ideal for power and switching applications, maintaining performance from -55°C to +150°C.
MULTICOMP PRO S1A Power Rectifier Specifications:
- Case: Molded Plastic
- Polarity: Indicated by cathode band
- Weight: 0.002 ounces, 0.053 grams
- Mounting Position: Any
- Reverse Voltage: 50 to 1000 Volts
- Forward Current: 1 Ampere
- Peak Forward Surge Current: 30 A (8.3 ms)
- Max. RMS Voltage: 35 to 700 V (depending on model)
- Max. Recurrent Peak Reverse Voltage: 50 to 1000 V
- Max. DC Blocking Voltage: 50 to 1000 V
- Max. Average Forward Rectified Current: 1A at 50°C
- Typical Junction Capacitance: 10 pF
- Typical Thermal Resistance: 30°C/W
- Operating Temperature Range: -55°C to +150°C
- Storage Temperature Range: Not specified
- Dimensions (in inches): Length 0.181, Width 0.157, Height 0.103
- Dimensions (in millimeters): Length 4.60, Width 4.00, Height 2.62
Buy the Multicomp Glass Passivated Rectifier – Reliable Power Diode for Industrial Applications
Purchase the multicomp series S1A+ surface mount glass passivated rectifier online today and enhance your power delivery systems with high reliability and efficiency. Designed for resistive and inductive loads, it features a wide voltage range from 50V to 1000V and a current capacity of 1A. Its UL 94V-0 plastic case ensures safety and durability, suitable for demanding industrial applications. Easy to mount in any position, this rectifier guarantees excellent performance across a temperature range from -55°C to +150°C, making it a trusted choice for power and switching needs.
Order your multicomp series S1A+ glass passivated rectifier today and ensure dependable power switching in your industrial projects.
