MULTICOMP SPC15237 High Density D-Sub Connector
The SPC15237 is a high-density, 26-pin D-sub connector with a right-angle plug configuration. It features gold-flash over nickel-plated brass contacts and is insulated with black PBT reinforced with 30% glass fiber. The connector employs solder termination and is rated for a maximum current of 5A. Its contact resistance is up to 15 milliohms, with an insulation resistance of at least 1000 megaohms. It operates within a temperature range of -55°C to +105°C, making it suitable for demanding applications. This connector is commonly used in communications and networking equipment.
MULTICOMP SPC15237 High Density D-Sub Connector Specifications:
- Shell Material: Steel, Nickel-Plated
- Insulator Material: PBT + 30% Fibre Glass, Black Colour
- Contact Material: Brass, Gold-Flash Over Nickel
- Current Rating: 5A
- Max. Contact Resistance: 15mΩ
- Min. Insulation Resistance: 1000MΩ at 500V DC
- Voltage: 500V AC for 1 minute
- Working Temperature: -55°C to +105°C
- No. of Contacts: 26
- Gender: Plug
- Pin Pitch: 2.29 mm
- PCB Layout: 12.060 mm x 40.25 mm
- Dimensions: 33.32 mm x 22.60 mm
Buy the Multicomp SPC15237 – Reliable D-Sub Connector for Industrial Applications
Purchase the Multicomp SPC15237 high-density 26-pin D-sub connector online today to ensure reliable connections in your industrial and networking projects. Featuring gold-flash contacts and a robust glass-reinforced PBT insulator, this connector is designed for durability and high performance. Perfect for communication, data transfer, and industrial automation, it offers a maximum current of 5A, low contact resistance of 15 milliohms, and operates over a temperature range of -55°C to +105°C. Secure your supply now for trusted quality and efficiency.
Order your Multicomp Series SPC15237 high-density D-sub plug today and give your projects the dependable quality they deserve for demanding industrial and communication applications.
