MULTICOMP SPC15368 D-Sub Connector
The SPC15368 is a 37-pin male D-sub connector with a straight PCB mount socket. It features gold-plated contacts over nickel brass for reliable connections and a PBT with glass fiber reinforced housing for durability. This connector is designed for solder termination, supporting a rated current of 5A. It provides a minimum insulation resistance of 1000MΩ and operates within a temperature range of -50°C to +105°C. Suitable for applications in communications, networking, and industrial environments, this connector offers robust performance and is rated highly by users.
MULTICOMP SPC15368 D-Sub Connector Specifications:
- Connector Type: D-Sub, Male, Straight PCB Socket
- Number of Contacts: 37
- Shell Size: 37P
- Shell Material: Steel, Tin-Plated
- Contact Material: Brass, Gold-Plated over Nickel
- Insulator: PBT & Glass Fiber-Reinforced, Blue Colour
- Current Rating: 5 Amps
- Dielectric Strength: 1,000V for One Minute
- Insulator Resistance: 1,000MΩ Min. at 500V DC
- Temperature Range: -50°C to +105°C
- Dimensions: 43.00 mm x 12.0 mm
- Operating Environment: Suitable for communications, networking, industrial applications
Buy the Multicomp Series D-Sub 37Pin Connectors: SPC15368
Order the Multicomp SPC15368 37-pin D-sub male connector online today for robust and reliable connections suitable for industrial, communication, and networking applications. Featuring gold-plated contacts over nickel-brass, a durable PBT housing reinforced with glass fiber, and rated for 5A, this connector ensures high performance in harsh environments. Operating across -50°C to +105°C, it guarantees excellent insulation resistance and dielectric strength. Purchase now and benefit from quick shipping, quality assurance, and industry-leading support to meet your electronic connection needs efficiently.
Get Multicomp SPC15368 today—built for durability and reliable solder connection in industrial environments.
Frequently Asked Questions
Where can I buy MULTICOMP SPC15368?
You can click on the BUY or RFQ button to purchase SPC15368 from an authorized MULTICOMP distributor.
How do I troubleshoot issues or seek technical support for part SPC15368?
You can download the SPC15368 datasheet or visit the MULTICOMP website for support.
Who is the manufacturer of SPC15368?
MULTICOMP
