MULTICOMP SPC15305 High-Density D-Sub Connector
The SPC15305 is a 44-pin high-density D-sub connector with PCB plug, featuring brass stamped pins with gold plating and tin-plated solder cups. It is insulated with black PBT plus 30% glass fiber, providing excellent mechanical strength and heat resistance. The steel shell is tin-plated for durability, conforming to UL94V-0 flammability standards. Rated for 5A, it ensures reliable electrical performance with a contact resistance not exceeding 15 milliohms. Suitable for communications, networking, computers, peripherals, and industrial applications, it operates effectively from -50°C to +100°C, ensuring versatility across diverse environments.
MULTICOMP SPC15305 High-Density D-Sub Connector Specifications:
- Current Rating: 5 Amps
- Contact Resistance: 15 milliohms MAX.
- Insulator Resistance: 1000 Megohms MIN.
- Voltage: 500 VAC for 1 Minute
- Temperature Range: -50°C to +100°C
- Shell Material: Steel, Tin Plated
- Insulator Material: PBT + 30% Glass Fiber, Black
- Contact Material: Brass, Stamped, Gold-Plated on Contact Area, Tin-Plated on Solder Cup
- Flammability: UL94V-0
- Design: 44 Pin High-Density D-Sub Connector
- Application: Data Communication, Networking, Industrial Systems, Peripherals
Buy the Brand SPC15305 – Reliable D-Sub Connector for Industrial Applications
Purchase the SPC15305 high-density 44-pin D-Sub connector online today and ensure reliable connections in your communication, networking, or industrial projects. Featuring brass gold-plated contacts, a durable steel shell, and environmentally resistant insulation, this connector operates from -50°C to +100°C, supporting up to 5A current. Perfect for applications requiring high reliability and high-performance connections, it’s easy to install and suitable for harsh environments. Order now to improve your system’s electrical performance and durability with this professional-grade connector.
Buy SPC15305 now and experience unmatched reliability and performance in high-density communication and industrial systems.
Frequently Asked Questions
Where can I buy MULTICOMP SPC15305?
You can click on the BUY or RFQ button to purchase SPC15305 from an authorized MULTICOMP distributor.
How do I troubleshoot issues or seek technical support for part SPC15305?
You can download the SPC15305 datasheet or visit the MULTICOMP website for support.
Who is the manufacturer of SPC15305?
MULTICOMP
