NKK Switches JB15HAP2F Low Profile Tactile Switch
This low-profile tactile push button switch offers reliable tactile feedback and compact design ideal for PCB mounting in electronic devices. Constructed with durable materials and sealed for environmental protection, it supports a high number of operations up to 5,000,000. The switch features flat or sculptured snap-on caps, multiple actuator options, and conforms to standards like IP67. Suitable for low-voltage logic circuits, it ensures long-lasting performance with high mechanical and electrical life, making it ideal for space-constrained applications requiring precision controls.
NKK Switches JB15HAP2F Low Profile Tactile Switch Specifications:
- Electrical Capacity (Resistive Load): 50mA @ 24V DC (Standard), 125mA @ 24V DC (High Operating Force)
- Contact Resistance: 50 milliohms maximum
- Insulation Resistance: 500 megohms minimum @ 250V DC
- Dielectric Strength: 250V AC for 1 minute minimum
- Mechanical Life: 5,000,000 operations minimum
- Electrical Life: 5,000,000 operations minimum
- Nominal Operating Force: 1.76N for JB15, 2.65N for JB1SH
- Total Travel: 0.250mm to 0.300mm
- Actuator Material: Glass fiber reinforced PBT, Polyacetal, Nitrile rubber seal
- Case & Base Material: UL94V-0 rated polyamide/Polycarbonate
- Terminals: Brass with silver plating, spring action conforming to .100” spacing
- Mounting: Panel or PCB via snap-on caps, right-angle or straight PC terminals
- Operating Temperature Range: 25°C to +70°C
- Humidity: 90-95% for 240 hours at 40°C
- Vibration & Shock Resistance: 10-55Hz, 50G acceleration
- Sealing: IP67 standard
- Soldering: Wave and manual soldering compatible
- Standards & Certifications: UL94V-0 rated case and base, suitable for low-voltage circuits
