NKK Switches S8AWF Industrial Toggle Switch
This standard-sized toggle switch is designed for reliable performance in multiple electrical applications. It supports resistive and inductive loads with a maximum capacity of 20A at 125V and 250V, suitable for industrial control, automation, and electrical instrumentation. Features include sturdy construction with chrome-plated brass contacts, IP67 sealing for splashproof protection, optional quick-connect terminals, and multiple toggle configurations such as single pole, double pole, and switch types with panel seals. Certified by UL and CSA, it offers durability with up to 50,000 mechanical operations, ensuring long-lasting service in demanding environments.
NKK Switches S8AWF Industrial Toggle Switch Specifications:
- Electrical Capacity: 20A at 125V and 250V, 8A at 30V DC
- Contact Resistance: 10 milliohms maximum
- Insulation Resistance: 1,000 megohms minimum at 500V DC
- Dielectric Strength: 2,000V AC for 1 minute
- Mechanical Life: 50,000 operations minimum
- Material: Brass with chrome plating, phenolic resin insulators, zinc-plated steel hardware, silver plated contacts
- Operating Temperature Range: -10°C to +70°C (14°F to 158°F)
- Sealing: IP67 standard for splashproof and lever lock panel seal models
- Mounting Torque: 1.47Nm (13 lb-in) for single nut, 2.94Nm (26 lb-in) for double nut
- Maximum Panel Thickness: 0.158 inches (4.0mm)
- Soldering: Manual soldering via Profile A, temperature and time specified in datasheet
- Certifications: UL Recognized, CSA Certified when ordered with markings
- Standards: Meets UL 94V-0 flammability, IP67 sealing in splashproof models, compliant with safety and environmental standards
Buy the NKK S8AWF – Reliable Toggle Switch for Industrial Applications
Purchase the NKK S8AWF toggle switch online today—designed for industrial control, automation, and electrical systems. This versatile switch offers IP67 sealing, high electrical capacity, and robust construction with chrome-plated brass contacts and phenolic insulators. It supports up to 50,000 operations, ensuring long-term reliability under harsh conditions. Certified by UL and CSA, it guarantees safety and compliance. Its various configurations, including single pole and double pole options with panel seals, make it ideal for demanding industrial applications. Order now for quick delivery and reliable performance.
Get NKK S8AWF toggle switch today—built for precision, durability, and environmental protection in demanding industrial environments.
Frequently Asked Questions
Where can I buy NKK Switches S8AWF?
You can click on the BUY or RFQ button to purchase S8AWF from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part S8AWF?
You can download the S8AWF datasheet or visit the NKK Switches website for support.
Who is the manufacturer of S8AWF?
NKK Switches
