NKK Switches UB15KKG015FFF Pushbutton Switch
A low-profile, illuminated pushbutton switch designed for PCB mounting, featuring solder terminals for easy installation. It offers bright LED indicators in multiple colors, with durable construction suitable for compact electronic control panels. The switch provides quick and sensitive actuation through snap-acting contacts, ensuring reliable performance with a long mechanical and electrical lifespan. Its robust housing construction with polycarbonate caps ensures resistance to impact and environmental factors. The product supports optional accessories like protective guards for enhanced safety and durability, making it perfect for industrial automation and control systems requiring clear visual signals and precise operation.
NKK Switches UB15KKG015FFF Pushbutton Switch Specifications:
- Housing/Bezel: UL94V-0 polycarbonate
- Contact Resistance: 50 milliohms max for silver, 100 milliohms max for gold
- Insulation Resistance: 200 megaohms min @ 500V DC
- Dielectric Strength: 1000V AC (contacts), 1500V AC (contacts & case)
- Mechanical Life: 1,000,000 operations minimum
- Electrical Life: 200,000 operations minimum
- Nominal Operating Force: 1.9N (square & rectangular), 2.55N to 3.1N (double pole)
- Travel: Pretravel 0.067” (1.7mm), Overtravel 0.024” (0.6mm), Total Travel 0.091” (2.3mm)
- Panel Thickness Compatibility: 0.039” to 0.126” (1.0mm to 3.2mm)
- LED Colors & Ratings: Red, Amber, Green, White, Blue; Voltage 3.2V to 2.0V depending on color
- LED Current: Typical 20mA, Peak 30mA
- Operating Temperature Range: -20°C to +50°C for non-illuminated, -25°C to +50°C for illuminated
- Certifications: UL Recognized, CSA Certified (order-specific)
Buy the NKK Series UB – Reliable Pushbutton Switch for Industrial Applications
Order the reliable NKK Series UB pushbutton switch online today. Its compact design, bright LED indicators, and durable polycarbonate housing make it ideal for industrial control panels. Easy to install with PCB mounting and solder terminals, this switch withstands extensive operation cycles, ensuring dependable performance. Optional accessories like protective guards enhance safety in challenging environments. Perfect for automation, machinery, and control systems, this switch provides clear visual signals and precise actuation, supporting efficient and safe operation of various industrial equipment.
Get NKK Series UB low-profile pushbutton switch today—designed for precision and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy NKK Switches UB15KKG015FFF?
You can click on the BUY or RFQ button to purchase UB15KKG015FFF from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part UB15KKG015FFF?
You can download the UB15KKG015FFF datasheet or visit the NKK Switches website for support.
Who is the manufacturer of UB15KKG015FFF?
NKK Switches
