NKK Switches UB15RKW035C Illuminated Pushbutton Switch
A low-profile illuminated pushbutton switch designed for PCB mounting and soldering applications. It features a compact design suitable for space-constrained electronic devices, with illumination for easy visibility.
NKK Switches UB15RKW035C Illuminated Pushbutton Switch Specifications:
- Poles & Circuits: Single & Double Pole
- Mounting Types: PCB Mounting, Snap-in Mounting
- Electrical Capacity: 5A @ 125/250V AC, 0.4VA max @ 28V AC/DC
- Contact Resistance: Silver contacts 50 milliohms max, Gold contacts 100 milliohms max
- Insulation Resistance: 200 megohms minimum @ 500V DC
- Dielectric Strength: 1,000V AC between contacts 1 minute, 1,500V AC between contacts and case 1 minute
- Mechanical Life: 1,000,000 operations
- Electrical Life: 200,000 operations
- Nominal Operating Force: 1.9N for single pole
- Travel: Pretravel 0.067” (1.7mm), Overtravel 0.024” (0.6mm), Total Travel 0.091” (2.3mm)
- Housing Material: Glass fiber reinforced polyamide (UL94V-0)
- LED Specifications: Bright LEDs in Red, Amber, Green, White, Blue; Forward Voltage: 1.85-3.2V; Peak Current: 20-30mA
- Operating Temperature Range: -20°C to +50°C for non-illuminated, -25°C to +50°C for illuminated
- Certification: UL recognized, CSA certified (order with markings)
Buy the NKK UB15RKW035C – Reliable Illumination Pushbutton for Industrial Applications
Purchase the NKK UB15RKW035C illuminated pushbutton switch online today for reliable performance in compact spaces. Designed for PCB mounting, it offers high durability, bright LED illumination, and smooth actuation, ideal for automation, control systems, and industrial equipment. Its robust construction handles millions of operations, ensuring long-term efficiency. Easy to install with snap-in mounting options, this switch is perfect for space-saving applications where visibility and dependability are crucial. Order now to enhance your electronic controls with a trusted brand.
Get NKK UB15RKW035C today—built for precision and long-lasting durability in electronic control panels.
Frequently Asked Questions
Where can I buy NKK Switches UB15RKW035C?
You can click on the BUY or RFQ button to purchase UB15RKW035C from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part UB15RKW035C?
You can download the UB15RKW035C datasheet or visit the NKK Switches website for support.
Who is the manufacturer of UB15RKW035C?
NKK Switches
