NKK Switches UB15SKG035C Low Profile Pushbutton
A low-profile, illuminated push-button switch designed for PCBs and soldering applications, offering easy activation and reliable illumination.
NKK Switches UB15SKG035C Low Profile Pushbutton Specifications:
- Poles & Circuits: Single & Double Pole
- Contact Material: Silver & Gold Plated
- Electrical Capacity: 5A @ 125/250V AC, 0.4VA max @ 28V AC/DC
- Contact Resistance: Silver 50 milliohms max, Gold 100 milliohms max
- Insulation Resistance: 200 MΩ min @ 500V DC
- Dielectric Strength: 1,000V AC between contacts, 1,500V AC between contacts & case
- Mechanical Life: 1,000,000 operations (momentary), 200,000 (resistive load)
- Operating Temperature: -25°C to +50°C for illuminated versions, -20°C to +70°C for non-illuminated
- Dimensions: Width & height vary depending on model, typical panel thickness 0.039” ~ 0.126”
- Housing Material: Glass fiber reinforced polyamide (UL94V-0)
- Solder Terminals: Straight PCB mount with solder lug
- LED Colors: Red, Amber, Green, White, Blue with various lens/diffuser options
Buy the NKK Series UB Low Profile Pushbuttons: UB15SKG035C
Order the NKK UB15SKG035C low profile illuminated push-button switch online today and enjoy easy installation, vibrant LED illumination, and long-lasting durability. Perfect for compact control panels, this switch offers quick actuation, high electrical capacity, and dependable performance in various industrial and electronic applications. Simplify your design with this reliable component that combines advanced features and compact size for efficient operation. Purchase now to enhance your project’s control and reliability with NKK's trusted quality.
Buy NKK UB15SKG035C low-profile illuminated push-button switch online now and experience unmatched reliability and performance for control panel applications.
Frequently Asked Questions
Where can I buy NKK Switches UB15SKG035C?
You can click on the BUY or RFQ button to purchase UB15SKG035C from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part UB15SKG035C?
You can download the UB15SKG035C datasheet or visit the NKK Switches website for support.
Who is the manufacturer of UB15SKG035C?
NKK Switches
