NKK Switches UB26NKW015D Illuminated Pushbutton
A low-profile illuminated pushbutton switch designed for quick and easy operation. Suitable for PCB mounting and soldering installation, providing reliable performance in various electronic applications.
NKK Switches UB26NKW015D Illuminated Pushbutton Specifications:
- Poles: Single Pole
- Circuits: SPDT
- Electrical Capacity: 5A @ 125/250V AC or 0.4VA max @ 28V DC
- Contact Resistance: 50 milliohms maximum for silver, 100 milliohms maximum for gold
- Insulation Resistance: 200 megohms minimum @ 500V DC
- Dielectric Strength: 1,000V AC between contacts for 1 minute, 1,500V AC between contacts & case for 1 minute
- Mechanical Life: 1,000,000 operations minimum
- Electrical Life: 200,000 operations minimum
- Nominal Operating Force: 1.9N for Square & Rectangular
- Travel: Pretravel 0.067” (1.7mm); Overtravel 0.024” (0.6mm); Total Travel 0.091” (2.3mm)
- Housing Material: Glass fiber reinforced polyamide (UL94V-0)
- Contact Material: Silver alloy or copper with gold plating
- LED Color Options: Red, Amber, Green, White, Blue
- LED Forward Voltage: 1.85V to 3.2V depending on color
- Operating Temperature Range: -25°C to +50°C for Illuminated, -20°C to +70°C for Nonilluminated
- Soldering Max Temperature: Profile A recommended during wave and manual soldering
- Certifications: UL recognized, CSA certified (order with markings), UL94V-0 housing
Buy the Buy NKK Switches UB26NKW015D Part Number UB26NKW015D Online
Order the NKK Switches UB26NKW015D low-profile illuminated pushbutton switch online today. Designed for reliable PCB mounting and soldering, it features durable construction, bright LEDs with various color options, and high electrical and mechanical life ratings. Perfect for compact control panels and industrial equipment, this switch provides easy operation with tactile feedback and excellent resistance to environmental factors. Enhance your electronic projects with this high-quality, UL recognized switch—easy to install and built for long-term performance.
Get NKK Switches UB26NKW015D today—built for precision and long-lasting durability in electronic control applications.
Frequently Asked Questions
Where can I buy NKK Switches UB26NKW015D?
You can click on the BUY or RFQ button to purchase UB26NKW015D from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part UB26NKW015D?
You can download the UB26NKW015D datasheet or visit the NKK Switches website for support.
Who is the manufacturer of UB26NKW015D?
NKK Switches
