NKK Switches WT15T Pushbutton Switch
Standard size pushbutton switch offering reliable performance in harsh environments with environmental sealing standards IP67 for dust and water protection, making it ideal for industrial, automation, and control applications. This toggle switch features a durable construction with heat-resistant resin housing, corrosion-resistant contacts, and versatile wiring options, including solder lug, screw lug, and wire lead terminals. Designed for ease of installation with sturdy hardware components, it withstands mechanical stresses, vibration, shock, and temperature ranges from -30°C to +70°C, ensuring durable operation in demanding conditions.
NKK Switches WT15T Pushbutton Switch Specifications:
- Electrical Capacity: 10A @ 125V AC, 6A @ 250V AC, 10A @ 30V DC
- Contact Resistance: 10 milliohms max for solder lug/screw terminal, 30 milliohms max for wire lead
- Insulation Resistance: 200 Megohms min @ 500V DC
- Dielectric Strength: 1,500V AC for 1 minute
- Mechanical Life: 50,000 operations (on-none-off/on-none-on), 30,000 (others)
- Materials & Finishes: Brass with chrome plating, fiberglass reinforced polyamide UL94V-0, melamine, nitrile rubber, copper with silver plating, heat resistant polyvinyl chloride
- Operating Temp Range: -30°C to +70°C
- Humidity & Vibration: 90-95% RH for 96 hours @ 40°C, 10-55Hz, amplitude 1.5mm
- Shock Resistance: 50G acceleration
- Ingress Protection: IP67 (dust tight and water protected during temporary immersion), IP60 for solder/screw lug models
- Mounting & Soldering: 1.47Nm torque, manual soldering profile A, operation in panel thickness up to 4mm with optional boots
Buy the Buy NKK Environmentally Sealed Toggle Switch Part Number WT15T Online
Purchase your NKK WT15T environment-sealed pushbutton switch online today and enjoy a reliable, durable solution for harsh industrial and control applications. Designed with IP67 protection against dust and water, this switch offers robust performance across a wide temperature range from -30°C to +70°C. Its versatile wiring options include solder lug, screw lug, and wire lead terminals, enabling easy integration into existing systems. Built with high-quality materials such as brass, fiberglass, and heat-resistant resin, this switch guarantees long-lasting operation in demanding environments, providing peace of mind and ensuring project success.
Order your NKK WT15T Series environment-sealed pushbutton switch today and ensure reliable operation in demanding industrial environments.
Frequently Asked Questions
Where can I buy NKK Switches WT15T?
You can click on the BUY or RFQ button to purchase WT15T from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part WT15T?
You can download the WT15T datasheet or visit the NKK Switches website for support.
Who is the manufacturer of WT15T?
NKK Switches
