NKK Switches WT23L Environmentally Sealed Pushbutton
This standard size pushbutton switch is environmentally sealed for reliable operation in harsh conditions, meeting IP67 standards for dust and water resistance. Made with a heat-resistant resin outer housing that complies with UL94V-0 flammability standards, it provides high arc and tracking resistance. Suitable for applications requiring robust environmental protection, it features durable terminals and contacts rated for 10A at 125V AC or 6A at 250V AC. Ideal for industrial machinery, automation, and control systems, ensuring dependable switching performance under severe environmental exposure.
NKK Switches WT23L Environmentally Sealed Pushbutton Specifications:
- Electrical Capacity: 10A @ 125V AC or 6A @ 250V AC
- Contact Resistance: 10 milliohms maximum for solder lug & screw terminal models; 30 milliohms maximum for wire lead models
- Insulation Resistance: 200 megohms minimum @ 500V DC
- Dielectric Strength: 1,500V AC for 1 minute minimum
- Mechanical Life: 50,000 operations minimum for most models
- Operating Temp Range: -30°C to +70°C
- Vibration Resistance: 10-55Hz, peak-to-peak amplitude of 1.5mm
- Shock Resistance: 50G acceleration, tested in all three axes
- Front Panel Seal: IP67, dust tight & water protected during temporary immersion
- Materials: Brass with chrome plating, fiberglass-reinforced polyamide housing, heat-resistant resin, Nitrile butadiene rubber seals, copper contacts with silver plating
- Mounting Hardware: Hex face nut, internal tooth lockwasher, optional boot assemblies for added protection
- Soldering & Mounting: Soldering time compliant with UL standards, mounting torque 1.47Nm (13 lbs.in)
- Standards & Certifications: UL VW-1 flammability, CSA recognized, IEC IP67 rated for front sealing
Buy the NKK Series WT Environmentally Sealed Toggle: WT23L
Purchase the NKK WT23L environmentally sealed pushbutton switch online today and ensure reliable operation in demanding environments. Built with high-quality materials for durability, it offers IP67 protection from dust and water, making it ideal for automation, machinery, and control panels exposed to harsh elements. Rated for 10A at 125V AC, this switch features a sturdy construction with a heat-resistant resin housing, corrosion-resistant terminals, and a long mechanical life of over 50,000 operations. Easy to install and compliant with industry safety standards, it guarantees consistent switching performance in severe conditions.
Buy NKK WT23L environmentally sealed pushbutton switch now and experience unmatched reliability and performance in harsh industrial environments.
Frequently Asked Questions
Where can I buy NKK Switches WT23L?
You can click on the BUY or RFQ button to purchase WT23L from an authorized NKK Switches distributor.
How do I troubleshoot issues or seek technical support for part WT23L?
You can download the WT23L datasheet or visit the NKK Switches website for support.
Who is the manufacturer of WT23L?
NKK Switches
