NVENT HOFFMAN THERM16F Industrial Thermostat Controller
The Therm16F thermostat controller is a reliable industrial control device designed to regulate temperature with a 40 to 100 F control range. It features a bimetal control element, snap contact transition, and robust construction with a plastic housing rated UL94V-0. Suitable for controlling heating and cooling systems, it offers a switching capacity of 4A at AC 250V, with adjustable temperature setpoints. Its compact dimensions of 2.64x1.97x1.50 inches ensure easy integration into various industrial environments, providing precise temperature regulation and durability in demanding conditions.
NVENT HOFFMAN THERM16F Industrial Thermostat Controller Specifications:
- Control Range: 40 to 100 F
- Switching Capacity: 4 A at AC 250V
- Minimum Switching Capacity: 30 W
- Maximum Switching Capacity NC: 1A at 250V
- Maximum Switching Capacity NO: 4 A at 250V
- Supply Voltage: 115V / 230V
- Ambient Temperature: -5.4 to +3.6 F (3/42K)
- Storage Temperature: -40 to +140 F
- Unit Dimensions: 2.64 x 1.97 x 1.50 inches (67 x 50 x 38 mm)
- Housing Material: UL94V-0 plastic
- Protection Rating: IEC IP20
- Control Type: Bimetallic snap contact
- Mounting: DIN rail clip included
- Weight: Approx. 60 g
- Certifications: UL, CSA, CE
- Application: Controls heaters and fans in industrial enclosures
- Connection: Tubular screw terminals for AWG 14 wire
- Hysteresis: Approx. 5 K
Buy the Horriman THERM16F – Reliable Temperature Control for Industrial Applications
Purchase the Horriman Therm16F thermostat controller online today and experience precise temperature regulation with a robust design. This industrial-grade device features adjustable control ranges from 40 to 100 F, a switching capacity of 4A at AC 250V, and compact dimensions ideal for various enclosures. Its UL94V-0 plastic housing ensures safety and durability, while DIN rail mounting facilitates easy installation. Perfect for controlling heaters and fans in demanding environments, it guarantees reliable, long-term operation to optimize your industrial processes.
Get Horriman THERM16F today—built for precise temperature regulation and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy NVENT HOFFMAN THERM16F?
You can click on the BUY or RFQ button to purchase THERM16F from an authorized NVENT HOFFMAN distributor.
How do I troubleshoot issues or seek technical support for part THERM16F?
You can download the THERM16F datasheet or visit the NVENT HOFFMAN website for support.
Who is the manufacturer of THERM16F?
NVENT HOFFMAN
