NXP FRDMKE15Z KE15Z Motor Control Module
The FRDM-KE15Z is a compact development platform designed for sensorless PMSM control applications using high-performance Kinetis E series MCUs. It features a 72 MHz ARM Cortex-M0+ core, up to 256 KB flash, and 32 KB RAM, with dedicated motor control peripherals including 6-channel FlexTimer for PWM generation and 2x 12-bit ADCs for phase and voltage measurement. The board supports precise hardware timing, synchronization, and over-current detection, making it ideal for scalable, high-reliability motor control solutions in industrial and automation settings.
NXP FRDMKE15Z KE15Z Motor Control Module Specifications:
- Core: ARM Cortex-M0+
- MCU Frequency: 72 MHz
- Flash Memory: Up to 256 KB
- SRAM: 32 KB
- PWM Channels: 6 (FlexTimer)
- ADC Resolution: 12-bit
- ADC Channels: 2 (Sensing phase currents and voltages)
- Voltage Range: Support for high-reliability environments, voltage regulation included
- Over-current detection: CMP with 3.197 V reference and filtering
- Timing Synchronization: Hardware based using dedicated peripherals
- Power Supply: 5 V USB or external, with reverse polarity protection
- Dimensions: Compact development form factor, compatible with standard prototyping tools
Buy the NXP Series KE15Z Sensorless PMSM Control: FRDMKE15Z
Purchase the NXP KE15Z development board online today to accelerate your sensorless PMSM control projects. Featuring a 72 MHz ARM Cortex-M0+ core, 6-channel PWM for precise motor drive, and dual 12-bit ADCs for accurate sensing, this compact platform supports scalable, high-reliability applications. Its hardware-timed synchronization, over-current detection, and reverse polarity protection ensure robust operation for industrial automation, robotics, and high-performance motor control in challenging environments. Order now and fast-track your motor control development!
Get NXP KE15Z sensorless PMSM control platform today—built for precision, reliability, and high-performance motor automation.
Frequently Asked Questions
Where can I buy NXP FRDMKE15Z?
You can click on the BUY or RFQ button to purchase FRDMKE15Z from an authorized NXP distributor.
How do I troubleshoot issues or seek technical support for part FRDMKE15Z?
You can download the FRDMKE15Z datasheet or visit the NXP website for support.
Who is the manufacturer of FRDMKE15Z?
NXP
