NXP NXH5104UKA1Z Serial EEPROM
The NXH5104 is a compact 4 Mbit serial EEPROM in wafer level chip scale package, supporting SPI interface, low power consumption, sector protection, and high reliability for industrial data storage and embedded system applications.
NXP NXH5104UKA1Z Serial EEPROM Specifications:
- Memory Capacity: 4 Mbit
- Package Type: Wafer Level Chip Scale Package (WLCSP) with 13 bumps
- Package Dimensions: 2.74 x 2.80 x 0.38 mm
- Supply Voltage Vop: 1.0 V to 2.0 V (wide range mode); 1.65 V to 2.0 V (fixed high mode)
- Input/Output Voltage Vppio: 1.0 V to 2.6 V, with 1.2 V signaling support
- Power Consumption: Active read current approx. 0.6 mA; write current approx. 0.7 mA; power down current < 5 pA
- Data Retention: 10 years
- Program Cycles: 500,000 program/erase cycles
- Temperature Range: -20°C to +85°C
- Interface: SPI compatible, supporting modes 0 and 3 up to 10 MHz
- Protection: Sector level write protection, status register protection, optional global protection
- Special Features: Self-timed programming, sector protection, auxiliary supply support, error correction code
Buy the NXP NXH5104 – Reliable Serial EEPROM for Industrial Applications
Enhance your industrial systems with the NXP NXH5104 serial EEPROM, offering 4 Mbit capacity, SPI interface, sector protection, and high reliability. Its compact wafer scale package consumes minimal power, with a voltage range of 1.0 V to 2.0 V, making it ideal for low-voltage, space-constrained applications. Features include self-timed write cycles, multiple protection modes, and 10-year data retention. Easy to integrate into embedded designs, it ensures robust data storage and efficient performance for demanding industrial environments.
Buy NXP NXH5104 now and experience top-tier reliability, low power consumption, and flexible sector protection for industrial electronics.
Frequently Asked Questions
Where can I buy NXP NXH5104UKA1Z?
You can click on the BUY or RFQ button to purchase NXH5104UKA1Z from an authorized NXP distributor.
How do I troubleshoot issues or seek technical support for part NXH5104UKA1Z?
You can download the NXH5104UKA1Z datasheet or visit the NXP website for support.
Who is the manufacturer of NXH5104UKA1Z?
NXP
