OMEGA CN8PT330EIPDC Temperature Process Controller
The CN8PT330EIPDC is a high-performance, versatile process controller with a bright, 4-digit 9-segment LED display. It offers firmware-based configuration, universal inputs including thermocouples, RTDs, thermistors, and process voltage/current, along with relay, DC pulse, and analog outputs. Features include full autotune PID with fuzzy logic, multiple alarm options, remote setpoint and ramp/soak programming. Equipped with USB, optional Ethernet and serial communications, and certified for multiple safety standards, it provides precise control for industrial and scientific applications in a compact form factor.
OMEGA CN8PT330EIPDC Temperature Process Controller Specifications:
- Display: 4-digit, 9-segment LED square, 42 DIN, external power supply (24 Vac) required
- Dimensions: 48H x 96W x 127mmD (1.89 x 3.78 x 5 inches)
- Power: 90 to 240 Vac or 12 to 36 Vdc, 3-4 W power consumption
- Inputs: Thermocouple (J, K, T, E, R, S, B, C, N), RTD (100/500/1000 Q), thermistor, process voltage/current, strain
- Input Range: Thermocouples -210°C to 2320°C; RTDs -200°C to 660°C; Thermistors -40°C to 150°C
- Outputs: 2 to 6 programmable outputs including SPST/SPDT relays, DC pulse, analog voltage/current (0–10V/0–20mA), isolated outputs
- Control Mode: PID with autotune, fuzzy logic adaptive control, ON/OFF, proportional, derivative, integrative modes
- Features: Ramp/soak programming (up to 99 programs, 8 segments each), extensive alarm logic, remote setpoint, cascade control
- Communications: USB (host mode), optional Ethernet (RJ45), serial RS232/RS485 with MODBUS®
- Certifications: UL, cUL, CE; NEMA 4x (IP65) front bezel, IEC recognized, time-lag and time-delay relays
Buy the Omega Series CN8PT Temperature Process Controller: CN8PT330EIPDC
Order the Omega CN8PT330EIPDC online today and experience cutting-edge process control with versatile inputs, multiple programmable outputs, integrated communications, and precise PID autotuning. Perfect for industrial automation, laboratory research, and demanding applications, this controller combines ease of setup with high accuracy, comprehensive alarm options, ramp/soak programs, and safety certifications. Enhance your system’s performance with reliable online purchasing—benefit from quick delivery, full firmware support, and the power of a compact, feature-rich control device designed for professionals.
Get Omega CN8PT330EIPDC today—built for precision, versatile inputs, and reliable industrial control.
Frequently Asked Questions
Where can I buy OMEGA CN8PT330EIPDC?
You can click on the BUY or RFQ button to purchase CN8PT330EIPDC from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part CN8PT330EIPDC?
You can download the CN8PT330EIPDC datasheet or visit the OMEGA website for support.
Who is the manufacturer of CN8PT330EIPDC?
OMEGA
