OMEGA PSW108 Industrial Pressure Switch
The pressure switch PSW108 is designed for industrial applications, offering a 3 to 100 psi range with adjustable deadband, resistive 15 A resistive electrical rating, and durable die-cast aluminum NEMA 4X (IP66) enclosure. Suitable for use with stainless steel, phosphor bronze, and Buna-N wetted materials, it features easy wiring access, external manual reset option, and a rugged, vibration-resistant design. Ideal for controlling processes involving various pressure ranges in demanding environments, it guarantees reliable operation and precise setpoint repetition under shock and vibration conditions.
OMEGA PSW108 Industrial Pressure Switch Specifications:
- Approval: UL listed
- Enclosure: Die-cast aluminum, epoxy-coated blue, NEMA 4X (IP66)
- Electrical Rating: 15 A resistive, 125/250/480 Vac
- Process Temperature: Stainless Steel -55 to 205°C, Phosphor Bronze -40 to 150°C, Buna-N -25 to 95°C
- Ambient Temperature: -40 to 70°C (except certain models -20 to 70°C)
- Vibration and Shock Resistance: Setpoint repeats after 15 g, 10 ms; 2.5 g, 5-500 Hz
- Dimensions: 191 mm height x 101 mm width x 60 mm depth (approx. 7.5 x 4 x 2.3 inches)
- Weight: Approximately 0.9 kg (2 lb)
- Switch Type: SPDT or DPDT, externally reset option, with lock adjustment
- Pressure Range: 3 to 100 psi, adjustable deadband, resistant to vibration and shock
Buy the Omega PSW108 – Reliable Pressure Switch for Industrial Applications
Purchase the Omega PSW108 pressure switch online today to ensure precise pressure control in your industrial system. Equipped with an adjustable deadband, resistive rated switch, and rugged NEMA 4X enclosure, it offers durability and reliable performance under shock and vibration. Its easy wiring, external manual reset, and versatile wetted materials make it suitable for demanding applications. Benefit from fast procurement, detailed specifications, and technical support by ordering online now for your pressure sensing and control needs.
Buy Omega PSW108 now and experience unmatched reliability and performance for demanding pressure control tasks.
Frequently Asked Questions
Where can I buy OMEGA PSW108?
You can click on the BUY or RFQ button to purchase PSW108 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part PSW108?
You can download the PSW108 datasheet or visit the OMEGA website for support.
Who is the manufacturer of PSW108?
OMEGA
