OMEGA CTXLRPW Circular Chart Recorder
The OMEGA CTXL Series circular chart recorders combine form and function in an easy-to-use, two-channel design. These recorders feature a large 8" diameter chart and dual-channel LCD readout, making them suitable for a variety of applications including temperature/humidity monitoring, dual thermocouple measurements, process voltage/current monitoring, and pH/temperature analysis. The CTXL offers convenient front panel programming, monitors min/max/avg values, and includes audible/visual alarms. It's designed for both benchtop and wall mount operation, making it versatile for industrial, laboratory, and even museum environments.
OMEGA CTXLRPW Circular Chart Recorder Specifications:
- Scale Size: 200 mm (8")
- Recording Duration: 1, 7, or 32 Days
- Display: Easy to Read Dual Channel Backlit LCD Readout
- Programming: Convenient Front Panel Programming/Operation
- Alarm: High/Low Audible/Visual Alarms
- Relays: Dual High Alarm Relays, Dual Low Alarm Voltage Outputs
- Mounting: Benchtop or Wall Mount
- Power: 4 D Batteries or Universal AC Adaptor
- Temperature Range: -17.7 to 49°C (0 to 120°F)
- Temperature Display Accuracy: ±1°C (2°F)
- Temperature Chart Accuracy: ±1.5°C (3°F)
- Temperature Display Resolution: 0.1° (F or C)
- Relative Humidity Range: 0 to 98% RH
- Relative Humidity Display Accuracy: ±3% RH (15 to 90% RH)
- Relative Humidity Chart Accuracy: ±4% RH (15 to 90% RH)
- Relative Humidity Display Resolution: 1% RH
- Remote Probe Distance: 12.2 m (40')
- Alarm Set Point Resolution Temperature: 0.5°C or °F
- Alarm Set Point Resolution Humidity: 1%RH
- Alarm Deadband Temperature: 0.5°C or °F
- Alarm Deadband Humidity: 3% RH
Buy the CTXL-RP-W OMEGA Circular Chart Recorder | myMectronic
Purchase the OMEGA CTXL-RP-W Circular Chart Recorder securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy OMEGA CTXLRPW?
You can click on the BUY or RFQ button to purchase CTXLRPW from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part CTXLRPW?
You can download the CTXLRPW datasheet or visit the OMEGA website for support.
Who is the manufacturer of CTXLRPW?
OMEGA
