OMEGA DMA15AAAAA1 Electromagnetic Flowmeter
The Picomag flowmeter by Endress+Hauser is a compact, electromagnetic device designed for reliable measurement of conductive liquids in industrial water, cooling, and rinsing water applications. Featuring wireless Bluetooth connectivity and SmartBlue App operation, it enables easy setup, diagnostics, and data access in challenging environments. Its robust, IP65/67 housing resists vibrations and shocks. Supporting various process connections and alloys, it measures flow, temperature, and conductivity with high accuracy, making it ideal for space-saving, precise, and compliant flow monitoring across diverse industrial settings.
OMEGA DMA15AAAAA1 Electromagnetic Flowmeter Specifications:
- Measuring principle: Electromagnetic flow measurement
- Fluid: Conductive liquids (210 pS/cm)
- Display: 1.4" TFT color, auto-rotatable
- Housing: 1.4404/316L, polycarbonate display
- Operation: SmartBlue App via Bluetooth, 10-Link process system
- Material: Electrodes - 1.4435/316L, Seals - FKM
- Process connection: External thread (G'/2", G34", G1", G2"), optional adapters (NPT, Tri-clamp, Victaulic)
- Process temperature: -10°C to +70°C, temporarily up to +85°C
- Power supply: DC 18-30V
- Degree of protection: IP65/IP67 (Type 4)
- In-/outputs: 2 configurable (4-20mA, pulse/switch, 2-10V, IO-Link, inputs)
- Communication: Bluetooth and IO-Link
- Nominal diameter: DN 15, 20, 25, 50
- Measuring range: 0.05 to 750 l/min depending on DN
- Process pressure: 16 bar
- Max. error: Flow ±0.8% o.r. + 0.2% o.f.s.
- Repeatability: Flow +0.2% o.f.s., temperature ±0.5°C
- Standards: IEC/EN 61326 EMC, UL listed, CE
- Certifications: Drinking water approval in progress
Buy the Endress+Hauser Series Picomag Electromagnetic Flowmeter: DMA15AAAAA1
Experience precise and reliable measurement of conductive liquids with the Endress+Hauser Picomag electromagnetic flowmeter. Its compact design, wireless Bluetooth connectivity, and user-friendly SmartBlue App enable quick setup, diagnostics, and data access even in challenging environments. Suitable for industrial water, rinse water, and cooling water applications, it supports multiple process connections and alloys. Its high accuracy, vibration resistance, and IP65/67 protection make it an ideal choice for space-efficient, compliant, and maintenance-friendly flow monitoring solutions in diverse industrial settings.
Get Endress+Hauser Picomag today—built for precise flow measurement and long-lasting durability in industrial water systems.
