OMEGA DP8PTDC Digital Panel Meter
The DP8PTDC series is a versatile digital panel meter designed for precise process measurement. It features 4-digit, 9-segment LED displays with a wide viewing angle, and supports various input types including thermocouples, RTDs, thermistors, voltage, current, and strain. Fully firmware configurable with automatic hardware recognition, it offers optional serial and Ethernet communication, two relay alarms, and an isolated analog output. Suitable for industrial environments, it ensures accurate readings with high stability and easy setup, making it ideal for various control and automation applications.
OMEGA DP8PTDC Digital Panel Meter Specifications:
- Input Types: Thermocouple, RTD, thermistor, analog voltage, analog current, strain
- Current Input: 4 to 20 mA, 0 to 24 mA scalable
- Voltage Input: -100 to 100 mV, -1 to 1V, -10 to 10 Vde scalable
- Thermocouple Types: J, K, T, E, R, S, B, C, N
- RTD: 100/500/1000 Ω, 2, 3, or 4-wire; curves 385, 392, 3916
- Thermistors: 2252 Ω, 5K Ω, 10K Ω
- Display: 4-digit, 9 segment LED with programmable color
- Resolution: 0.1°C for temperature, scalable process inputs
- Sampling Rate: 20 samples/sec, 24-bit ADC
- Firmware: Fully firmware configurable with auto hardware recognition
- Communication: USB standard, optional Ethernet (TCP/IP, web server), RS232/RS485 MODBUS
- Alarm Outputs: Two mechanical relays, configurable for high/low/band triggers
- Power Supply: 90-240 Vac or 12-36 Vdc low voltage option
- Operating Conditions: 0°C to 50°C, 90% RH, industrial environments
- Dimensions: 48 H x 48 W x 127 mm D (DP8Pt series), mounting cutout 45 x 92 mm, NEMA 1 front bezel
- Approvals: UL, cUL, CE, with safety testing for electrical isolation
Buy the Omega Series Digital Panel Meters: DP8PTDC
Purchase the Omega DP8PTDC digital panel meter online today and experience high accuracy, versatile input options, and easy setup. Equipped with firmware auto recognition, it simplifies configuration for thermocouples, RTDs, thermistors, voltage, and current signals. Featuring optional serial and Ethernet communication, two relay alarms, and an isolated analog output, it is ideal for demanding industrial environments. Its robust design ensures reliable operation, clear LED display, and compliance with safety standards, making it the perfect choice for process measurement and automation needs.
Get Omega DP8PTDC today—built for precision, versatile input support, and long-lasting durability in industrial automation.
Frequently Asked Questions
Where can I buy OMEGA DP8PTDC?
You can click on the BUY or RFQ button to purchase DP8PTDC from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part DP8PTDC?
You can download the DP8PTDC datasheet or visit the OMEGA website for support.
Who is the manufacturer of DP8PTDC?
OMEGA
