OMEGA DPI8 Digital Panel Meter
The OMEGA® iSeries is an advanced industrial instrument combining high-accuracy digital panel meters and fully functional PID controllers, suitable for temperature, process, and strain measurements. Featuring user-friendly setup, programmable color displays, and embedded Ethernet connectivity, it supports thermocouples, RTDs, pressure transducers, and strain gages. Offering 0.5°C accuracy, digital filtering, and multiple communication options, the iSeries is optimal for precise industrial monitoring and control, ensuring reliable operation in demanding environments with extended warranties and versatile input configurations.
OMEGA DPI8 Digital Panel Meter Specifications:
- Accuracy: ±0.5°C (temperature), 0.03% reading (process/strain)
- Display: 4-digit 9-segment LED with programmable color
- Input Types: Thermocouple, RTD, analog voltage/current
- Thermocouple Types: J, K, T, E, R, S, B, C, N, L
- RTD Input: 100/500/1000 ohm; 2, 3, or 4-wire with 0.00385 or 0.00392 curve
- Voltage Input: 0-100 mV, 0-1 V, 0-10 Vdc; Impedance: 10 MΩ for 100 mV; 1 MΩ for Vdc
- Current Input: 0-20 mA; Resolution: 10/1 V
- Temperature Stability: RTD 0.04°C/°C; Thermocouple 0.05°C/°C @ 25°C
- Power: 90-240 Vac ±10%, 50-400 Hz, or 12-36 Vdc/ Vac with low voltage option
- Communication: Ethernet (TCP/IP, HTTP), RS232/RS422/RS485 (programmable from menu)
- Environmental: 0 to 55°C, 90% RH non-condensing; durable NEMA 4/IP65 front bezel options
- Dimensions: 48 H x 96 W x 127 mmD for i/8 series; panel cutout 45 H x 92 W mm
- Weight: 295 g (i/8 series)
Buy the OMEGA DPI8 – Reliable Temperature Monitoring for Industrial Applications
Purchase your OMEGA DPI8 digital panel meter now to benefit from precise temperature, process, and strain measurement. Features include color-changing display, Ethernet connectivity, multiple input options, and high accuracy. Designed for easy configuration with a durable, NEMA 4/IP65 rated front bezel, it supports thermocouples, RTDs, and current/voltage inputs. Ideal for industrial environments requiring reliable data acquisition, real-time control, and remote communication. Order online today for fast delivery and exceptional performance in your automation and control projects.
Order your OMEGA Series DPI8 temperature and process meter today and enhance your industrial monitoring with high precision and versatile connectivity.
Frequently Asked Questions
Where can I buy OMEGA DPI8?
You can click on the BUY or RFQ button to purchase DPI8 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part DPI8?
You can download the DPI8 datasheet or visit the OMEGA website for support.
Who is the manufacturer of DPI8?
OMEGA
