OMEGA EWSMB Environmental Sensor
Omega's economical wall-mount sensors are ideal for accurate environmental monitoring in offices, laboratories, and data centers. They include thermocouple, RTD, thermistor models, temperature/humidity, and pressure sensors with industry-standard outputs like 4 to 20 mA or 1 to 5 Vde. Made from durable ABS, they offer reliable temperature measurement up to 60°C with high accuracy. Compatible with data loggers, controllers, and process meters, these sensors feature 1 m leads coated for insulation, ensuring precise data collection in static or moving air environments. They suit various industrial and environmental settings perfectly.
OMEGA EWSMB Environmental Sensor Specifications:
- Enclosure Material: Acrylonitrile butadiene styrene
- Dimensions: 45 H x 54 W x 79 mm L (1.78 x 2.12 x 3.12")
- Thermocouple Max Temperature: 60°C (140°F)
- Accuracy: +1.1°C (1.98°F)
- Sensor Types: J, K, T, E
- RTD Max Temperature: 60°C (140°F)
- RTD Accuracy: +1°C (1.8°F)
- RTD Sensor Type: 100 @ Pt 0.00385
- RTD Lead Material: PFA insulated, 3-conductor 26 AWG stranded nickel-plated copper
- Thermistor Max Temperature: 60°C (140°F)
- Thermistor Accuracy: +0.2°C (0.36°F)
- Thermistor Lead Material: PVC insulated, 2-conductor 22 AWG stranded nickel-plated copper
- Temperature Transmitter Range: -18 to 57°C (0 to 135°F)
- Temperature/Humidity Range: 5 to 95% RH (non-condensing)
- Temperature/Humidity Accuracy @ 25°C: +0.7°C or +4% RH (lower limit), +1.4°C or +3% RH (full range)
- Barometric Pressure Range: 20.8 to 32 inHg (10.2 to 15.7 psi)
- Output: User-selectable 4 to 20 mA or 1 to 5 Vde
- Power Supply: 12 to 24 Vdc
- Loop Resistance: Calculated as (V supply — 8 V)/0.02A
- Certifications: RoHS 2 Compliant
- Compatibility: Compatible with most process meters, controllers, recorders, data loggers, and data acquisition systems
Buy the Buy Omega Environmental Sensors Part Number EWS-RTD Online
Enhance your environmental monitoring with Omega's reliable wall-mount sensors, offering accurate temperature, humidity, and pressure readings. Compatible with various data acquisition systems, these sensors feature industry-standard outputs like 4 to 20 mA and 1 to 5 Vde, with durable ABS enclosures for long-lasting use. Ideal for offices, laboratories, and industrial settings, they provide high accuracy up to 60°C. Invest in a cost-effective, dependable solution for precise environmental data collection today.
Get Omega EWS-RTD today—designed for precise temperature measurement and durable industrial performance.
Frequently Asked Questions
Where can I buy OMEGA EWSMB?
You can click on the BUY or RFQ button to purchase EWSMB from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part EWSMB?
You can download the EWSMB datasheet or visit the OMEGA website for support.
Who is the manufacturer of EWSMB?
OMEGA
