OMEGA FLR6105D Flow Sensor
This rugged inline flow sensor is suited for process control and industrial applications, measuring flow rates of 0.5 to 5.0 GPM with 2% accuracy. It features an aluminum body, compatible with oil, and provides digital flow rate and total flow readings. It mounts in any position, with a sturdy cast aluminum enclosure, and includes a 4 to 20 mA, 0 to 5 V, or 0 to 10 Vdc output. The device operates reliably within a temperature range of -29 to 116°C and supports remote monitoring with up to 300 meters cable extension, making it ideal for industrial fluid management.
OMEGA FLR6105D Flow Sensor Specifications:
- Flow Range: 0.5 to 5.0 GPM
- Medium: Oil
- Material: Aluminum body, C360 brass components
- Accuracy: 2% full scale
- Operating Temperature: -29 to 116°C (-20 to 240°F)
- Maximum Pressure: 3500 psig (liquids)
- Power Supply: 10-30 Vdc @ 0.75 W for 0-5 Vdc output, 12-30 Vdc @ 0.75 W for 0-10 Vdc, Loop-powered 4-20 mA
- Protection: Reverse polarity and current limiting
- Display: 8-digit rate, 8-digit totalizer
- Response Time: 1 second
- Cable Extension: Up to 300 meters
- Enclosure: Anodized aluminum with silicone gasket, IP52/IP54 rated
- Connection: 4-pin plug
- Maximum Signal Transmission: 4-20 mA limited by cable resistance, 0-5 Vdc and 0-10 Vdc up to 300 meters
Buy the Omega FLR6105D – Reliable Oil Flow Sensor for Industrial Applications
Discover the durability and precision of the Omega flow sensor, designed specifically for oil and industrial fluid applications. With a flow range of 0.5 to 5.0 GPM and 2% accuracy, this device ensures reliable process control. Its aluminum body and IP54-rated enclosure withstand harsh environments, making it ideal for continuous industrial operation. The sensor provides real-time digital flow rate and totalizer readings, with versatile outputs compatible with existing systems. Easy to install in any position, it supports cable extension up to 300 meters for remote monitoring, delivering seamless integration into your control system.
Order your Omega Series FLR6105D flow transmitter today and enhance your fluid management with a durable, high-accuracy industrial sensor.
