OMEGA FLR7130D Flow Sensor
This flow meter is engineered for accurate process control in industrial systems, with a flow range of 3 to 30 GPM suitable for oil. Constructed with an anodized aluminum body, it ensures durability in harsh environments. The device offers 2% FS accuracy, can be mounted in any position, and features a digital flow rate and total flow indicator for real-time monitoring. It supports multiple outputs including 4-20 mA, 0-5 V, and 0-10 V signals, with rugged construction and tailored in-field compensation for specific gravity, viscosity, pressure, and temperature.
OMEGA FLR7130D Flow Sensor Specifications:
- Flow Range: 3 to 30 GPM
- Medium: Oil
- Body Material: Anodized Aluminum
- Accuracy: 2% FS
- Maximum Pressure: 3500 psig (liquids), 1000 psig (gases)
- Temperature Range: -29 to 116°C (-20 to 240°F)
- Power Requirements: 0 to 5 Vdc (10-30 Vde @ 0.75 W), 0 to 10 Vdc (12-30 Vde @ 0.75 W), 4-20 mA Loop (up to 30 Vde)
- Output Circuit Protection: Reverse polarity and current limit
- Display: 8-digit rate, 8-digit totalizer, 0.70" high numeric display, 0.35" high alphanumeric
- Response Time: 1.0 sec
- Physical Dimensions: Compact rugged in-line design with aluminum enclosure
- Enclosure Rating: NEMA 12 and 13 (IP52/54)
- Connections: 4-pin standard, with integral cable up to 300 m (1000')
- Materials: Polycarbonate lens, silicone gasket, FKM O-rings, T316 SS spider and retaining ring, PPS/ceramic internal magnet
Buy the Omega FLR7130D – Reliable Flow Sensor for Industrial Applications
Discover the precision and durability of the Omega FLR7130D flow sensor, perfect for oil flow measurement in industrial setups. Easy to install and mount in any position, it provides reliable real-time data with a 2% FS accuracy. Multiple output options ensure compatibility with various control systems. Its robust aluminum casing safeguards against harsh environments, and its digital display simplifies operations. Invest in this proven flow sensor today and enhance your process control precision, ensuring optimal performance and operational efficiency.
Order your Omega Series FLR7130D flow meter today and equip your industrial systems with a highly accurate, durable flow measurement solution.
Frequently Asked Questions
Where can I buy OMEGA FLR7130D?
You can click on the BUY or RFQ button to purchase FLR7130D from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part FLR7130D?
You can download the FLR7130D datasheet or visit the OMEGA website for support.
Who is the manufacturer of FLR7130D?
OMEGA
