OMEGA HFSTWKM EMI Filter Connector
The Ferrite Core OMEGA connector is designed for EMI and RFI suppression in electronic circuits, featuring a Nickel-Zinc ferrite core and a high-temperature Liquid Crystal Polymer shell. It is a heavy-duty, solid pin male connector with removable write-on windows, suitable for stranded or solid wires up to 14 AWG. The connector includes a combination Phillips/Slotted captive screws, is rated for 120°C ferrite core effectiveness, and 260°C LCP material temperature. Its impedance at 25 MHz is 35 Ω, and at 100 MHz is 70 Ω, ensuring reliable electromagnetic interference suppression.
OMEGA HFSTWKM EMI Filter Connector Specifications:
- Ferrite Core Effectiveness: 120°C (248°F)
- LCP Material Temperature Rating: 260°C (500°F)
- Impedance: 35 Ω at 25 MHz; 70 Ω at 100 MHz
- Connector Type: Male, with removable write-on windows
- Shell Material: Nickel-Zinc ferrite core with high-temperature liquid crystal polymer
- Wire Compatibility: Stranded or solid wire up to 14 AWG
- Screws: Combination Phillips/Slotted captive screws
- Dimensions: 11.2 mm (0.44 inches) diameter, 127.0 mm (5 inches) length
- Temperature Ratings: Ferrite core at 120°C, shell at 260°C
- Additional windows available for enhanced calibration or labeling
- Heavy-duty construction with code and earth-tone color options
- Cadmium-free shell for environmentally safe applications
Buy the Buy OMEGA EMI/RFI Ferrite Core Connectors Part Number HFSTWKM Online
Purchase the OMEGA EMI filter connector online today for reliable electromagnetic interference suppression and high-temperature performance. Designed with a Nickel-Zinc ferrite core and durable liquid crystal polymer shell, this heavy-duty male connector accepts wires up to 14 AWG, ensuring secure connections. Features removable write-on windows for easy labeling, captive screws for durability, and impedance suitable for high-frequency applications. Enhance your electronic assembly with a dependable, environmentally safe connector built to withstand demanding conditions and provide efficient EMI mitigation.
Get OMEGA HFSTWKM today—built for EMI suppression and high-temperature durability with removable write-on features.
Frequently Asked Questions
Where can I buy OMEGA HFSTWKM?
You can click on the BUY or RFQ button to purchase HFSTWKM from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part HFSTWKM?
You can download the HFSTWKM datasheet or visit the OMEGA website for support.
Who is the manufacturer of HFSTWKM?
OMEGA
