OMEGA LCR500 High-Accuracy Load Cell
The Omega LCR-500 is a high-accuracy, rugged S-Beam load cell designed for industrial applications. It features a 500 lb capacity, high precision output of 3 mV/V, and is compatible with various meters like DP41-S. Operating with a maximum excitation of 10VDC, it offers excellent linearity of ±0.03%, hysteresis of ±0.02%, and repeatability of ±0.10%. The device withstands overloads up to 150% and ultimate overload of 300%, with an IP55 protection rating. Constructed from lightweight aluminum, it performs reliably in temperatures from -18°C to 71°C, making it ideal for sensing and instrumentation tasks in harsh environments.
OMEGA LCR500 High-Accuracy Load Cell Specifications:
- Capacity: 500 lb (227 kgf)
- Output: 3 mV/V ±0.25%
- Excitation: 10 VDC, 15 V max
- Linearity: ±0.03%
- Hysteresis: ±0.02%
- Repeatability: ±0.10%
- Temperature Range: -18°C to 71°C (0°F to 150°F)
- Overload Capacity: 150% of capacity
- Ultimate Overload: 300% of capacity
- Protection Level: IP55
- Material: Lightweight aluminum
- Application: Industrial sensing, instrumentation
- Includes 5-point NIST calibration
Buy the Buy Omega LCR-500 High-Accuracy Load Cell Online
Purchase the Omega LCR-500 high-accuracy load cell online today and experience superior measurement precision for industrial applications. Its rugged construction, IP55 protection, and reliable performance ensure accurate sensing in harsh environments. Equipped with a 500 lb capacity, this load cell provides precise output of 3 mV/V, with excellent linearity, hysteresis, and repeatability. Ideal for various instrumentation tasks, it includes a 5-point NIST calibration. Order now for dependable performance in your industrial or sensing projects, with fast delivery and full support.
Get Omega LCR-500 today—built for precision and long-lasting durability in industrial environments.
Frequently Asked Questions
Where can I buy OMEGA LCR500?
You can click on the BUY or RFQ button to purchase LCR500 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part LCR500?
You can download the LCR500 datasheet or visit the OMEGA website for support.
Who is the manufacturer of LCR500?
OMEGA
