OMEGA SP0020 Infrared Temperature Sensor
The Omega Smart IR Temperature Probe is a compact, stainless steel infrared sensor measuring surface temperature without contact, suitable for industrial environments. It detects temperatures from -70°C to 380°C with 1°C accuracy, featuring configurable emissivity, adjustable response time, and intelligent data logging. The probe offers two optical field of view options, 6:1 and 10:1, for precise measurement over various surfaces including plastics, paper, and painted metals. Engineered for heavy-duty use with CE and RoHS compliance, it integrates advanced IoT electronics for secure connectivity, alarms, and data storage, ideal for diverse industrial temperature monitoring applications.
OMEGA SP0020 Infrared Temperature Sensor Specifications:
- Temperature Range: -70 to 380°C
- Accuracy @ 0 to 50°C: 1°C or 1% of reading
- Repeatability: 1°C or 1% of reading
- Emissivity: 0.01 to 1.00, software adjustable
- Response Time: 1 second
- Spectral Response: 5.5 to 14 microns
- Supply Power: 3.3 Vdc, 0.05 W max
- Field of View: 6:1 (SP-001) or 10:1 (SP-002)
- Construction: Stainless Steel
- Sensor Dimensions: 12 mm OD x 67 mm L
- Thread Mounting: 12 mm OD x 33.5 mm L
- Weight: 35 g
- Environmental Rating: NEMA 6, IP67
- Operating Temperature: -40 to 85°C
- Vibration Resistance: 10 Gs from 10 Hz to 500 Hz
- Agency Approvals: CE, EMC 2014/30/EU, LVD 2014/35/EU
Buy the Buy Omega IR Temperature Sensor Part Number SP0020 Online
Order the Omega infrared temperature sensor today for accurate, non-contact surface temperature measurement from -70°C to 380°C. Equipped with adjustable emissivity, configurable optical field of view, and robust stainless steel housing, it’s ideal for industrial environments. The device offers IoT connectivity, data logging, and real-time alarms, ensuring reliable operation in heavy-duty applications. Easy to install and factory calibrated, this sensor is perfect for monitoring plastics, metals, and organic materials, delivering precise readings and enhanced safety for your industrial processes.
Get Omega SP0020 today—built for precision and long-lasting durability in industrial temperature monitoring.
Frequently Asked Questions
Where can I buy OMEGA SP0020?
You can click on the BUY or RFQ button to purchase SP0020 from an authorized OMEGA distributor.
How do I troubleshoot issues or seek technical support for part SP0020?
You can download the SP0020 datasheet or visit the OMEGA website for support.
Who is the manufacturer of SP0020?
OMEGA
