ONSEMI MMBTA63LT1G PNP Darlington transistor
The MMBTA63LT1G is a PNP silicon Darlington transistor designed for automotive and industrial applications, providing high current gain and reliable switching. Qualified under AEC-Q101 standards, it features Pb-Free, Halogen-Free, and RoHS compliance, making it environmentally friendly. Suitable for control and amplification tasks, this device operates within a maximum collector-emitter voltage of -30 V and a collector current of -500 mA with thermal resistances tailored for efficient heat dissipation. Its compact SOT-23 package ensures easy integration into various electronic circuits, offering robust performance in demanding environments.
ONSEMI MMBTA63LT1G PNP Darlington transistor Specifications:
- Collector-Emitter Voltage: -30 V
- Collector-Base Voltage: -30 V
- Emitter-Base Voltage: -10 V
- Collector Current (Continuous): -500 mA
- Total Device Dissipation (Pp): 225 mW at 25°C on FR-5 board
- Derate above 25°C: 18 mW/°C
- Junction-to-Ambient Thermal Resistance: 556 °C/W
- Total Device Dissipation (Alumina): 300 mW at 25°C
- Derate above 25°C: 24 mW/°C
- Junction Temperature Range: -85°C to +150°C
- Package: SOT-23, TO-236
- Maximum Lead Thickness Includes Finish
- Lead Spacing and Dimensions as per industry standards
- RoHS compliant, Pb-Free, Halogen-Free
Buy the Buy ON Semiconductor PNP Darlington Transistor Part Number MMBTA63LT1G Online
Order the ON Semiconductor PNP Darlington transistor in SOT-23 package online today. Designed for automotive and industrial control systems, it offers high current gain up to 20,000 and excellent thermal performance. Its RoHS compliance and Pb-Free construction ensure environmental safety. With a maximum collector-emitter voltage of -30 V and a continuous collector current of -500 mA, this device guarantees reliable operation in rigorous environments. Perfect for amplification and switching tasks, it is easy to install and integrate into your electronic designs, ensuring long-lasting durability and precision performance.
Get ON Semiconductor MMBTA63LT1G today—built for high current gains and reliable switching in demanding automotive and industrial applications.
Frequently Asked Questions
Where can I buy ONSEMI MMBTA63LT1G?
You can click on the BUY or RFQ button to purchase MMBTA63LT1G from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part MMBTA63LT1G?
You can download the MMBTA63LT1G datasheet or visit the ONSEMI website for support.
Who is the manufacturer of MMBTA63LT1G?
ONSEMI
