ONSEMI MURD320T4G Ultra-fast Power Rectifier
The MURD320T4G is an ultra-fast switching power rectifier in a DPAK surface-mount package, designed for efficient power supplies, inverters, and free-wheeling diodes. It features corrosion-resistant surfaces and easily solderable leads, ensuring durability and ease of assembly. With a recovery time of 35 nanoseconds, low forward voltage drop, and low leakage current, it provides high reliability for demanding industrial and automotive applications. Its epoxy molded case ensures mechanical robustness, making it ideal for compact power management solutions in various electronic devices.
ONSEMI MURD320T4G Ultra-fast Power Rectifier Specifications:
- Case: Epoxy, Molded
- Maximum Repetitive Reverse Voltage: 200 V
- Maximum Instantaneous Forward Voltage Drop: 0.95 V at 3 A, 25°C
- Maximum Instantaneous Reverse Current: 5 A at 25°C, 500 A at 125°C
- Recovery Time: 35 ns at 1 A, 25°C
- Peak Repetitive Forward Current: 6.0 A
- Maximum Working Peak Reverse Voltage: 200 V
- Average Rectified Forward Current: 3.0 A at To = 158°C
- Thermal Resistance - Junction-to-Case: 6 °C/W
- Thermal Resistance - Junction-to-Ambient: 80 °C/W
- ESD Ratings: > 8 kV Human Body Model, > 400 V Machine Model
- Operating Junction Temperature Range: -65°C to +175°C
Buy the ON Semiconductor Series SURD Rectifier: MURD320T4G
Purchase the ON Semiconductor MURD320T4G ultra-fast power rectifier online today. Engineered for switching power supplies, inverters, and industrial power management, it features a molded epoxy case, corrosion-resistant surfaces, and solderable leads. With a recovery time of 35 ns, low forward voltage drop, and low leakage currents, this device ensures durability and efficiency. Ideal for compact and high-performance power circuits, it guarantees reliability, high-speed operation, and compliance with RoHS standards for global sustainability. Order now for fast delivery and superior power solutions.
Buy ON Semiconductor MURD320T4G now and experience unmatched reliability and performance in switching power applications.
Frequently Asked Questions
Where can I buy ONSEMI MURD320T4G?
You can click on the BUY or RFQ button to purchase MURD320T4G from an authorized ONSEMI distributor.
How do I troubleshoot issues or seek technical support for part MURD320T4G?
You can download the MURD320T4G datasheet or visit the ONSEMI website for support.
Who is the manufacturer of MURD320T4G?
ONSEMI
