ONSEMI NCV1009DR2G Voltage Reference Device
The NCV1009 is a precision 2.5 V shunt regulator diode with low dynamic impedance, wide operating range, and on-chip trimming for minimal voltage and temperature drift. It features a third terminal for voltage adjustments up to +5.0%, making it ideal as a pin-to-pin replacement for similar devices like LT1009CZ and LM136Z-2.5, without external trim networks. Designed for automotive and industrial applications, it guarantees temperature stability and meets Mil Std 883C ESD requirements, with Pb-free options available for environmental safety.
ONSEMI NCV1009DR2G Voltage Reference Device Specifications:
- Operating Voltage Range: 5.0 V to 35 V
- Initial Tolerance: 0.2%
- Maximum Dynamic Impedance: 0.6 Ω
- Temperature Range: -40°C to +125°C
- Reverse Breakdown Voltage: 2.492 V to 2.508 V at 1 mA
- Reverse Dynamic Impedance: 0.2 to 1.4 Ω
- Temperature Stability: ±18 mV over 0°C to 70°C
- Storage Temperature Range: -65°C to +150°C
- Package Options: SOIC-8, TO-92, Pb-Free variants
- Maximum Junction-to-Ambient Thermal Resistance: SOIC-8 165°C/W, TO-92 170°C/W
- Peak Soldering Temperature: 260°C (Wave), 240°C (Reflow)
Buy the Buy ON Semiconductor NCV1009DR2G Part Number NCV1009DR2G Online
Order ON Semiconductor NCV1009DR2G today for a highly accurate 2.5 V reference diode, ideal for automotive, industrial, and precision measurement applications. This device features low dynamic impedance and guaranteed temperature stability, ensuring reliable operation over wide temperature ranges. Its on-chip trimming enables calibration, eliminating the need for external trim networks. Available in multiple packages, including Pb-free options, the NCV1009DR2G combines performance, durability, and environmental safety. Purchase online for fast delivery and technical support to enhance your electronic designs.
Get ON Semiconductor NCV1009DR2G today—designed for precision voltage reference and automotive reliability with low temperature drift.
