ONSEMI SGL160N60UFDTU Ultrafast IGBT
Fairchild's ultrafast IGBT from the UFD series offers low conduction and switching losses, making it ideal for motor control, general inverters, robotics, and power supplies. Designed for high-speed switching with a low saturation voltage of 2.1 V at 80A, it features high input impedance and rapid switching capabilities with a typical t, of 75 ns. Its robust specifications include a collector-emitter voltage of 600 V, collector current of 160 A at 25°C, and a maximum junction temperature of 150°C, ensuring reliable performance in demanding industrial applications.
ONSEMI SGL160N60UFDTU Ultrafast IGBT Specifications:
- Collector-Emitter Voltage: 600 V
- Gate-Emitter Voltage: +20 V
- Collector Current at 25°C: 160 A
- Collector Current at 100°C: 80 A
- Pulsed Collector Current: 300 A
- Diode Forward Current: 25 A
- Maximum Power Dissipation: 250 W at 25°C, 100 W at 100°C
- Operating Junction Temperature: -55 to +150 °C
- Storage Temperature Range: -55 to +150 °C
- Maximum Lead Soldering Temp: 300 °C for 5 seconds
- Thermal Resistance Junction-to-Case: 0.5 °C/W (IGBT) / 0.83 °C/W (Diode)
- Switching Delay: ~40 ns, Rise Time: ~101 ns, Fall Time: ~75-150 ns
- Capacitances: Input ~5000 pF, Output ~600 pF, Reverse Transfer ~200 pF
- Maximum Power Dissipation: 250 W, Junction temp: 150°C
Buy the Fairchild SGL160N60UFD – Reliable Ultrafast IGBT for Industrial Applications
Purchase the ultrafast IGBT from the UFD series online today to ensure efficient motor control, inverter performance, and power supply reliability. This high-speed, low-loss device offers 600V, 160A capabilities, and rapid switching with a typical delay of 75 ns. Designed for demanding industrial applications, it features a low saturation voltage of 2.1V at 80A, high input impedance, and excellent thermal stability. Get your reliable power switching component now and optimize your industrial automation projects.
Buy Fairchild SGL160N60UFD ultrafast IGBT now and experience unmatched reliability and high-speed switching performance for your industrial needs.
