OMRON ELECTRONIC COMPONENTS G2R14AC120 Industrial Power Relay
The G2R-14-AC120 is a fully sealed industrial power PCB relay featuring an SPDT contact configuration and straight through-hole PCB termination. It has a dielectric strength of 5000V between the coil and contacts, with surge resistance up to 10,000V. The relay is designed with Class B coil insulation, supports a rated resistive load of 8A at 250VAC or 30VDC, and operates with a coil power of 900mW. It also offers maximum contact resistance of 30 milliohms and minimum insulation resistance of 1000 megaohms. Common applications include HVAC systems, consumer electronics, and security devices.
OMRON ELECTRONIC COMPONENTS G2R14AC120 Industrial Power Relay Specifications:
- Contact Form: SPDT (1c)
- Coil Power: 900 mW
- Rated Load: 8A at 250VAC, 30VDC
- Dielectric Strength: 5,000 V between coil and contacts
- Surge Resistance: 10,000 V
- Maximum Contact Resistance: 30 milliohms
- Insulation Resistance: ≥ 1000 megaohms at 500VDC
- Coil Insulation Class: B
- Termination: Straight through-hole PCB mounting
- Dimensions: Approximate size based on model (not specified)
- Application: HVAC systems, consumer electronics, security devices
Buy the Omron G2R14AC120 – Reliable PCB Power Relay for Industrial Applications
Buy your Omron G2R14AC120 relay online now and ensure reliable operation in your HVAC, security, and consumer electronics systems. This fully sealed relay features an SPDT contact configuration supporting up to 8A at 250VAC or 30VDC load, with outstanding surge resistance of 10,000V and dielectric strength of 5,000V. Its straight through-hole PCB mounting makes installation straightforward, ensuring stable connections. Whether for new designs or replacements, this relay provides long-lasting durability, high safety margins, and optimal performance suited for demanding industrial environments. Purchase today to secure efficient and dependable system operation.
Order your Omron G2R14AC120 fully sealed PCB relay today and enhance your projects with dependable performance and high insulation strength.
Frequently Asked Questions
Where can I buy OMRON ELECTRONIC COMPONENTS G2R14AC120?
You can click on the BUY or RFQ button to purchase G2R14AC120 from an authorized OMRON ELECTRONIC COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part G2R14AC120?
You can download the G2R14AC120 datasheet or visit the OMRON ELECTRONIC COMPONENTS website for support.
Who is the manufacturer of G2R14AC120?
OMRON ELECTRONIC COMPONENTS
