OMRON ELECTRONIC COMPONENTS G6DN1ASLDC5 PCB Power Relay
The G6DN-1A-L is a high-durability, SPST-NO PCB power relay designed for switching loads up to 5A at 250 VAC or 30 VDC. It features a compact 20 x 5.08 x 12.5 mm size, crossbar-twin contact for high contact reliability, and low power consumption of approximately 110 mW. Suitable for applications like programmable controllers, temperature controllers, and building automation, it meets safety standards EN61010-1 and EN61010-2-201, with an electrical durability of 100,000 operations, ensuring long-lasting, reliable performance in industrial settings.
OMRON ELECTRONIC COMPONENTS G6DN1ASLDC5 PCB Power Relay Specifications:
- Size: 20 x 5.08 x 12.5 mm
- Contact Rating: 5A at 250 VAC, 2A at 30 VDC
- Contact Material: Silver alloy with gold plating
- Coil Voltage: 5VDC, 12VDC, 24VDC (customizable)
- Coil Resistance: 22.0-46.0 ohms depending on voltage
- Coil Power Consumption: Approx. 110 mW
- Operate Time: Max 10 ms
- Release Time: Max 5 ms
- Insulation Resistance: Min. 1000 MΩ at 500 VDC
- Dielectric Strength: 300 V between coil and contacts
- Temperature Range: -40°C to +90°C
- Approval Standards: EN61010-1, EN61010-2-201, UL V-0 flammability class
- Weight: Approx. 3 g
Buy the Buy OMRON G6DN-1A-L PCB Power Relay Part Number G6DN1ASLDC5 Online
Purchase the OMRON G6DN-1A-L PCB Power Relay online today. This compact, high-durability relay offers reliable switching up to 5A at 250 VAC or 30 VDC. Designed for industrial automation, building control, and temperature regulation, it features a sealed enclosure, low power consumption, and meets international safety standards EN61010-1 and UL V-0. Its long electrical lifespan ensures sustained performance for demanding control system applications, making it an essential component for efficient, reliable operation.
Get OMRON G6DN-1A-L PCB Power Relay today—built for high contact reliability and long-lasting durability in industrial automation.
Frequently Asked Questions
Where can I buy OMRON ELECTRONIC COMPONENTS G6DN1ASLDC5?
You can click on the BUY or RFQ button to purchase G6DN1ASLDC5 from an authorized OMRON ELECTRONIC COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part G6DN1ASLDC5?
You can download the G6DN1ASLDC5 datasheet or visit the OMRON ELECTRONIC COMPONENTS website for support.
Who is the manufacturer of G6DN1ASLDC5?
OMRON ELECTRONIC COMPONENTS
