OMRON ELECTRONIC COMPONENTS XG5U0001 Crimped Connector Socket
Crimped MIL connector sockets for discrete wires designed for secure and space-saving connections in electronic assemblies. Features include one-hand insert locking, compatibility with AWG22 to AWG28 wires, and UL94 V-2 flame retardant materials like fiber-glass reinforced PBT and POM resin. With a wide operating temperature range of -55°C to 105°C, these sockets offer robust electrical performance, with a contact resistance of 1,000 MQ min. at 500 V DC and UL and CSA certifications, making them ideal for industrial, automation, and electronic connection applications.
OMRON ELECTRONIC COMPONENTS XG5U0001 Crimped Connector Socket Specifications:
- Material: Fiber-glass reinforced PBT resin (UL94 V-2), POM resin, phosphor bronze with gold plating
- Contact Resistance: 1,000 MQ min. at 500 V DC
- Voltage Rating: 500 VAC for 60 s
- Operating Temperature: -55°C to 105°C
- Wire Range: AWG22 to AWG28 (twisted wires)
- Number of contacts: Models available with 10, 17, 22, 26, 28 contacts
- Dimensions (approximate): Length varies with model, contact pitch 22.86 mm for certain models
- Certifications: UL Listed, CSA Certified
- Insertion/Withdrawal Force: 0.29 N min. per contact (individual pull-out force)
- Crimping Method: Uses specified crimping tools, optional contact removal with XY2E-0003
- Storage: Avoid dust, high humidity, and gases like ammonia and sulfides
- Temperature Range: -55°C to 105°C, no icing
Buy the Omron Series XG5N Crimped Connector: XG5U0001
Purchase the Omron XG5U0001 Crimped Connector Socket online today. Designed for secure connection of discrete wires with high-quality materials, these sockets feature easy one-hand locking, wide temperature range, and UL certifications. Perfect for industrial control panels, automation systems, and electronic devices, they ensure reliable performance and space-saving installation. Use the recommended crimping tools for proper assembly. Order in bulk for consistency in your projects and benefit from fast delivery and customer support. Make your wiring safer and more efficient now.
Get Omron XG5U0001 today—built for precise, secure electronic connections and long-lasting durability.
Frequently Asked Questions
Where can I buy OMRON ELECTRONIC COMPONENTS XG5U0001?
You can click on the BUY or RFQ button to purchase XG5U0001 from an authorized OMRON ELECTRONIC COMPONENTS distributor.
How do I troubleshoot issues or seek technical support for part XG5U0001?
You can download the XG5U0001 datasheet or visit the OMRON ELECTRONIC COMPONENTS website for support.
Who is the manufacturer of XG5U0001?
OMRON ELECTRONIC COMPONENTS
