Phoenix Contact 1704861 8-Position Push-in Plug
The Phoenix Contact PTSM 0,5/ 8-P-2,5 WH plug connector is a miniature component ideal for connecting wires to THR and SMD base strips. Its 2.5mm pitch allows for compact designs, while the push-in spring connection simplifies installation and maintenance. This connector is commonly used in automation, control systems, and power distribution panels where reliable and space-saving connections are required. It's rated for a nominal current of 6A and a voltage up to 160V, ensuring safe and efficient power transmission.
Phoenix Contact 1704861 8-Position Push-in Plug Specifications:
- Nominal current: 6 A
- Rated voltage (III/2): 160 V
- Number of positions: 8
- Pitch: 2.5 mm
- Connection method: Push-in spring connection
- Color: white
- Contact surface: Tin
- Packing unit: 1 pc
- Weight per Piece (excluding packing): 2.2 g
- Custom tariff number: 85369010
- Country of origin: Poland
- Length: 15 mm
- Height: 5 mm
- Dimension a: 17.5 mm
- Insulating material group: I
- Rated surge voltage (III/3): 2.5 kV
- Rated surge voltage (III/2): 2.5 kV
- Rated surge voltage (II/2): 2.5 kV
- Rated voltage (III/3): 100 V
- Rated voltage (II/2): 320 V
- Nominal cross section: 0.5 mm²
- Maximum load current: 6 A
- Insulating material: HT PA
- Flammability rating according to UL 94: V0
- Stripping length: 6 mm
- Conductor cross section solid min.: 0.14 mm²
- Conductor cross section solid max.: 0.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 0.5 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve min.: 0.25 mm²
- Conductor cross section flexible, with ferrule without plastic sleeve max.: 0.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 20
- Minimum AWG according to UL/CUL: 26
- Maximum AWG according to UL/CUL: 20
- eCl@ss 4.0: 272607xx
- eCl@ss 4.1: 27260701
- eCl@ss 5.0: 27260701
- eCl@ss 5.1: 27141190
- eCl@ss 6.0: 27260704
- eCl@ss 7.0: 27440402
- eCl@ss 8.0: 27440402
- eCl@ss 9.0: 27440402
- ETIM 3.0: EC001121
- ETIM 4.0: EC002638
- ETIM 5.0: EC002637
- UNSPSC 6.01: 30211810
- UNSPSC 7.0901: 39121409
- UNSPSC 11: 39121409
- UNSPSC 12.01: 39121409
- UNSPSC 13.2: 39121409
Buy the 1704861 PHOENIX CONTACT 8-Position Push-in Plug | myMectronic
Securely purchase the Phoenix Contact 1704861 plug connector online for reliable component sourcing.
Buy Now
Frequently Asked Questions
Where can I buy Phoenix Contact 1704861?
You can click on the BUY or RFQ button to purchase 1704861 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1704861?
You can download the 1704861 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1704861?
Phoenix Contact
