Phoenix Contact 1804836 PCB Header
This green PCB header supports a nominal current of 20 A and a rated voltage of 630 V (category III/2). It features six positions with a pitch of 7.62 mm, and a contact surface made of tin for reliable electrical connection. Designed for PCB mounting via wave soldering, it includes a linear pin layout with solder pins approximately 5 mm long. An optional mounting flange enhances vibration resistance and EMC shielding, making it suitable for industrial electronic assemblies requiring durable, high-quality connections. Compatible with PC 4 plugs and includes protection against mismatching with coding profiles.
Phoenix Contact 1804836 PCB Header Specifications:
- Nominal current: 20 A
- Rated voltage: 630 V (category III/2)
- Number of positions: 6
- Pitch: 7.62 mm
- Contact surface: Tin
- Mounting: Wave soldering
- Pin length: 5 mm
- Color: Green
- Mounting flange: Optional, Order No. 1827570
- Compliance: CSA, UL Recognized, cUL Recognized, LR, GL, BV, DNV, RS, EAC
Buy the Phoenix Contact Series PCB Header: 1804836
Purchase the Phoenix Contact PCB Header 1804836 online today and experience reliable, high-current connections suitable for industrial applications. Its six-position design, 20 A current rating, and 630 V voltage withstand ensure durability and safety. The wave-solderable mounting makes installation straightforward, while the tin contact surface provides excellent electrical conductivity. Compatible with PC 4 plugs, and equipped with optional vibration-resistant flange and EMC shielding, this component is perfect for professionals seeking sturdy, precision-engineered PCB connection solutions for demanding environments.
Get Phoenix Contact 1804836 today—built for high-current industrial PCB connections with vibration-resistant mounting and EMC shielding.
Frequently Asked Questions
Where can I buy Phoenix Contact 1804836?
You can click on the BUY or RFQ button to purchase 1804836 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part 1804836?
You can download the 1804836 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of 1804836?
Phoenix Contact
