Phoenix Contact 3002763 PCB Terminal Block
The Phoenix PTFIX 12X1.5 BU is a PCB terminal block designed for reliable electrical connections in industrial and electronic setups. Featuring 12 connection points and a 1.5 mm pitch, it offers secure push-in connection technology, supporting solid and flexible conductors from 0.14 mm² to 2.5 mm² or AWG 26 to 14. It is rated for a nominal voltage of 450 V and current of 17.5 A, with a compact profile measuring 24.9 mm in width, 17.7 mm in height, and 21.6 mm in length, ensuring space-saving installation on DIN rails and direct mounting options.
Phoenix Contact 3002763 PCB Terminal Block Specifications:
- Number of connections: 12
- Pitch: 1.5 mm
- Connection method: Push-in
- Max load current: 224 A
- Rated voltage: 450 V
- Nominal current: 17.5 A
- Width: 24.9 mm
- Height: 17.7 mm
- Length: 21.6 mm
- Color: Blue
- Insulating material: PA
- Flammability rating: UL 94V-0
- Operating temperature: -60°C to 105°C
- Conductor compatibility: 0.14 mm² - 2.5 mm², AWG 26 - 14
- Standards: IEC 60998-2-2
- Certifications: UL Recognized, cUL, DNV GL, VDE
Buy the Phoenix Series PTFIX PCB Terminal Block: 3002763
Secure your electrical installations with the Phoenix PTFIX 12X1.5 BU terminal block, offering 12 connections, push-in technology, and reliable rating for industrial use. Its compact design allows easy DIN rail snapping and direct mounting, saving valuable space. Made with high-quality insulative materials, it satisfies UL 94V-0 flammability standards and withstands temperatures from -60°C to 105°C. Ideal for professionals seeking durable, efficient, and easy-to-install terminal solutions for complex electrical systems.
Buy Phoenix series PTFIX 12X1.5 BU terminal block now and experience unmatched reliability and space-saving performance for industrial wiring.
