Phoenix Contact DFKMSTB252G508 Base Strip Connector
The PHOENIX CONTACT DFK-MSTB 2,5/ 2-G-5,08 base strip connector provides a robust and flexible connection solution for electronic devices and control systems. Designed with a 5.08mm pitch and accommodating up to 2 positions, this connector allows for both solder and slip-on plug-in connections, offering versatility in assembly and maintenance. It's ideal for applications requiring secure connections to device or housing panels, and its compatibility with MSTB and MSTBT plugs ensures seamless integration into existing systems. The connector's robust construction and reliable performance make it suitable for industrial environments demanding high-quality connections.
Phoenix Contact DFKMSTB252G508 Base Strip Connector Specifications:
- Nominal current: 12 A
- Rated voltage (III/2): 320 V
- Number of positions: 2
- Pitch: 5.08 mm
- Connection method: Solder/Slip-on connection
- Color: green
- Contact surface: Tin
- Mounting: Direct mounting
- Insulating material group: I
- Rated surge voltage (III/3): 4 kV
- Rated surge voltage (III/2): 4 kV
- Rated surge voltage (II/2): 4 kV
- Rated voltage (III/3): 320 V
- Rated voltage (II/2): 630 V
- Connection in acc. with standard: EN-VDE
- Nominal cross section: 2.5 mm²
- Maximum load current: 12 A
- Insulating material: PA
- Flammability rating according to UL 94: V2
- Conductor cross section solid min.: 0.2 mm²
- Conductor cross section solid max.: 2.5 mm²
- Conductor cross section flexible min.: 0.2 mm²
- Conductor cross section flexible max.: 2.5 mm²
- Conductor cross section AWG min.: 24
- Conductor cross section AWG max.: 12
- Packing unit: 1 pc
- Minimum order quantity: 50 pc
- Weight per Piece (excluding packing): 3.54 g
- Custom tariff number: 85366990
- Country of origin: Germany
Buy the 0707248 PHOENIX CONTACT Base Strip Connector | myMectronic
Purchase the PHOENIX CONTACT DFK-MSTB 2,5/ 2-G-5,08 base strip connector securely and efficiently online.
Buy Now
Frequently Asked Questions
Where can I buy Phoenix Contact DFKMSTB252G508?
You can click on the BUY or RFQ button to purchase DFKMSTB252G508 from an authorized Phoenix Contact distributor.
How do I troubleshoot issues or seek technical support for part DFKMSTB252G508?
You can download the DFKMSTB252G508 datasheet or visit the Phoenix Contact website for support.
Who is the manufacturer of DFKMSTB252G508?
Phoenix Contact
